System And Components
1N-4455 LINES GP-AIR COMPRESSORS/N 6NC1-UP; 08Z1-UP; 13Z1-UP
Group No: 1N-4455
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7N5645 | 1 TUBE AS-OUTLET | 1 | |
| 7K1517 | 2 ELBOW | 2 | |
| 2N1287 | 3 ELBOW-FLARED | 3 | |
| 1N4458 | 4 TUBE AS | 1 | |
| 1W4785 | 5 TUBE AS | 1 | |
| 5K9240 | 6 ELBOW-FLARED | 1 | |
| 1P7125 | 7 GOVERNOR AS-AIR COMPRESSOR | 1 | |
| 2S2923 | 7A COVER AS | 1 | |
| 2K8198 | SEAL-O-RING | 1 | |
| 9F2247 | 9 PLUG-PIPE (1/8-27-THD) | 4 | |
| 1D4541 | 10 BOLT (5/16-18X3-IN) | 2 | |
| 9M1974 | 11 WASHER-HARD (8.8X16X2-MM THK) | 5 | |
| 5K9238 | 12 CONNECTOR | 1 | |
| 8N0449 | 13 TUBE AS | 1 | |
| 1B3057 | 14 CLIP | 1 | |
| 7E5354 | 15 BRACKET | 1 | |
| 1A9579 | 16 BOLT (5/16-18X1.5-IN) | 2 | |
| 6K1972 | 17 ELBOW-FLARED | 1 | |
| 9N0869 | 18 WASHER-HARD (8.8X25.5X2-MM THK) | 1 | |
| 9N3040 | 19 HOSE AS | 1 | |
| 5K9244 | 20 ELBOW-FLARED | 1 | |
| 3B6552 | 21 ELBOW-PIPE | 1 | |
| 5F5434 | 22 VALVE AS-VENT | 1 | |
| 6K8079 | 23 CONNECTOR | 1 | |
| 3B7764 | 24 BUSHING (REDUCING) | 1 | |
| 5S0003 | 25 NUT (5/16-18-THD) | 2 | |
| 3S8536 | 26 SPACER (0.406X0.656X0.38-IN THK) | 1 | |
| 8T6764 | 27 PLUG-PIPE (1/8-27-THD) | 1 | |
| 9M0402 | KIT-GOVERNOR OVERHAUL (AIR COMPRESSOR) | 1 |
