System And Components
8X-6805 HOUSING GP-REAR AXLES/N 3PR1-UP
Group No: 8X-6805
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B8686 | 1 FITTING-GREASE (1/8-27 PTF) | 3 | |
| 5D3501 | 2 PLUG | 1 | |
| 6F4868 | 3 GASKET | 2 | |
| 6G7339 | 4 PLATE | 1 | |
| 6G7346 | 5 PLATE | 1 | |
| 6V0444 | 6 BEARING-SPHERICAL | 1 | |
| 4205462 | 7 PIN | 2 | |
| 7J3296 | 8 RING-LOCK | 4 | |
| 7J3297 | 9 BEARING | 2 | |
| 8M5576 | 10 PLUG-MAGNETIC (REAR AXLE) | 1 | |
| 8W9826 | 11 RING | 1 | |
| 8X0570 | 12 SHIM PACK (INCLUDES 33-SHIMS) | 1 | |
| 8X0572 | 13 WASHER-THRUST (127.5X152.4X3-MM THK) | 1 | |
| 8X0573 | 14 PIN | 1 | |
| 3673098 | 15 CAP AS | 2 | |
| 8X0585 | 16 PLATE | 1 | |
| 8X6782 | 17 HOUSING GP-REAR AXLE | 1 | |
| 8X8414 | 18 WASHER (24X95X16-MM THK) | 4 | |
| 9C4937 | 19 BREATHER AS (REAR AXLE HOUSING) | 1 | |
| 1760370 | 20 SUPPORT AS | 1 | |
| 2114921 | 21 ROD (LATERAL) | 1 | |
| 0307765 | 22 FITTING | 1 | |
| 1D4593 | 23 BOLT (5/8-11X5.5-IN) | 8 | |
| 1D4626 | 24 BOLT (7/8-9X2.75-IN) | 6 | |
| 2B2391 | 25 BOLT (7/8-9X10-IN) | 2 | |
| 2J3505 | 26 NUT-FULL (7/8-9-THD) | 2 | |
| 3R2300 | 28 BOLT (1-1/4-7X4.5-IN) | 16 | |
| 4D6578 | 29 STUD-TAPERLOCK (3/4-10X3-IN) | 2 | |
| 4K0684 | 30 WASHER-HARD (34X55X6-MM THK) | 16 | |
| 5F9338 | 31 BOLT (1-8X7-IN) | 8 | |
| 5P8247 | 32 WASHER-HARD (17X32X3.5-MM THK) | 8 | |
| 5P8249 | 33 WASHER-HARD (24X41.5X4-MM THK) | 8 | |
| 5P8250 | 34 WASHER (28X49X5-MM THK) | 8 | |
| 6D1915 | 35 STUD-TAPERLOCK (3/4-10X3.81-IN) | 24 |
