System And Components
526-0864 WIRING GP-CEMS/N NGH1-UP
Group No: 526-0864
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 9 | |
| 2901993 | 2 STRAP-CABLE | 18 | |
| 3108570 | 3 BRACKET | 1 | |
| 3349645 | 4 SLEEVE AS | 3 | |
| 3473880 | 5 BRACKET | 4 | |
| 3633548 | 6 SPACER (14.3X6.4X6.4-MM THK) | 8 | |
| 4415127 | 7 SENSOR AS-NITROGEN OXIDE (ENGINE OUTPUT) | 1 | |
| 4415128 | 8 SENSOR AS-NITROGEN OXIDE (EXHAUST PIPE OUT) | 1 | |
| 4882652 | 9 SLEEVE | 15 | |
| 5253189 | 10 HARNESS AS-ENGINE (CLEAN EMISSIONS MODULE) | 1 | |
| 5254027 | 11 SENSOR AS-TEMPERATURE (EXHAUST) | 1 | |
| 8T4138 | 12 BOLT (M6X1X20-MM) | 10 | |
| 8T4224 | 13 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 3413624 | 14 CLIP (LADDER) | 10 | |
| 8T4189 | 15 BOLT (M8X1.25X20-MM) | 1 | |
| 9X8256 | 16 WASHER (6.6X12X2-MM THK) | 16 | |
| 8T4200 | 17 BOLT (M8X1.25X16-MM) | 5 | |
| 7X2533 | 18 BOLT (M6X1X35-MM) | 4 |
