482-7524 DRIVE GP-CIRCLES/N EN51-UP

Group No: 482-7524

Part Number	Part Name	Qty
2G0339	1 WASHER-SPECIAL	1
2G0478	2 PLATE-CLUTCH	10
5K5288	3 SEAL GP-DUO-CONE	2
5K5129	RING-SEALING	2
5T8060	4 ADAPTER	1
6G1539	5 COVER	1
6G5538	6 COVER	1
6G5542	7 SPACER (119.2X178X9.3-MM THK)	2
6Y7953	8 DISC-FRICTION	11
8D4522	9 SHIM (0.127-MM THK)	4
8D4523	10 SHIM (0.254-MM THK)	2
8D7333	11 COLLAR	1
2656724	12 HOUSING-DRIVE	1
3071959	13 SHIM (0.13-MM THK)	6
3071960	14 SHIM (0.25-MM THK)	1
3071961	15 PLATE	1
3071962	16 SHIM (0.5-MM THK)	4
4505243	17 SHAFT	1
5582101	18 PINION	1
5239068	19 GEAR-WORM	1
4506182	20 GEAR-WORM	1
4546333	21 CAGE AS	1
7J2604	21A BUSHING	1
4612375	22 FILM-INFORMATION (FINAL DRIVE OIL)	1
0S1585	23 BOLT (1/2-13X1.5-IN)	4
1653930	24 BOLT (3/8-16X1.625-IN)	4
1A1415	25 NUT (1-7/8-12-THD)	1
1B5174	26 PLUG-PIPE	1
2B0858	27 PLUG-PIPE	1
2D6533	28 SEAL-O-RING	1
3J2333	29 BUSHING	2
4D4823	30 STUD-TAPERLOCK (5/8-11-THD)	4
4K0367	31 NUT-FULL (5/8-11-THD)	4
5H3252	32 SEAL-O-RING	1
5K7143	33 BOLT-SELF-LOCKING (1/2-13X1.5-IN)	2
5M2894	34 WASHER-HARD (10.2X18.5X2.5-MM THK)	4
5P8245	36 WASHER-HARD (13.5X25.5X3-MM THK)	6
5P8247	37 WASHER-HARD (17X32X3.5-MM THK)	4
5S7379	38 BOLT (3/8-16X0.875-IN)	4
6G1536	39 SPACER (69.88X90X13-MM THK)	1
6G5539	40 GASKET	1
6G6122	41 SPRING-DISC	1
6V5686	42 BOLT (M16X2X50-MM)	3
8D3984	43 CONE-BEARING	2
8D3986	44 CUP-BEARING	2
8D5054	45 WASHER-HARD (17X30X3-MM THK)	3
8D7343	46 WASHER-THRUST (3.12X4.62X0.09-MM THK)	1
8D7424	47 SPACER (48X81X6-MM THK)	1
8T0336	48 FITTING-PRESSURE RELIEF	1
8T4896	49 WASHER-HARD (10.2X18.5X2.5-MM THK)	4
8W6179	50 WASHER-THRUST	1
