Assembly
100%

265-6710 LIFT GP-BLADES/N EN61-UP

Group No: 265-6710
Part NumberPart NameQty
8D33291 PIN2
26510992 PIN2
39068373 ARM AS (RH)1
8D33093A BUSHING1
8D33113B BUSHING1
8T49104 BOLT (M12X1.75X60-MM)1
46383615 PLATE1
8T42236 WASHER-HARD (13.5X25.5X3-MM THK)1
18939257 BOLT (M20X2.5X170-MM)4
8T32828 WASHER-HARD (22X35X3.5-MM THK)8
26510989 LOCK2
436382810 BAR AS1
8D950710A BUSHING4
9D331310B BUSHING2
9D333310C RING-RETAINING1
390683811 ARM AS (LH)1
8D330911A BUSHING1
8D331111B BUSHING1
6V774212 NUT-FULL (M20X2.5-THD)4
7X085113 NUT (M24X3-THD)6
8T067414 BOLT (M24X3X180-MM)6
6V823715 WASHER (26X44X4-MM THK)12
265671716 RETAINER2
7X256317 BOLT (M20X2.5X60-MM)4
265671818 SHIM (0.13-MM THK)8
265671919 SHIM (0.25-MM THK)6
265672020 SHIM (0.5-MM THK)2
8D330821 SEAL2
5H567222 SEAL-O-RING2
8D326823 WASHER (93.68X133.35X2.39-MM THK)2
8D326924 WASHER (3.635X5.25X0.075-IN THK)4
8D326725 WASHER (4.265X5.84X0.075-IN THK)4
8D326626 WASHER (109X149X2.39-MM THK)2
8D330727 SEAL2
2S843928 SEAL-O-RING2
265671629 YOKE AS2
2G823429A RING1
9D658830 SEAL-LIP TYPE8
8D324531 WASHER (3.515X7X0.075-IN THK)8
8D324432 WASHER (90.47X177.8X2.39-MM THK)4
8D324733 WASHER (71.42X152.4X2.39-MM THK)4
8D325134 WASHER (70X151X1.22-MM THK)10
8D325235 WASHER (70X151X0.76-MM THK)10
8T412336 WASHER (22X35X3.5-MM THK)4
265109737 LOCK2
9D658938 SEAL-LIP TYPE1
