System And Components
306-9418 LINES GP-ENGINE OILS/N SSP151-UP
Group No: 306-9418
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1294422 | 1 SPACER (13X25X64-MM THK) | 1 | |
| 3676025 | 2 REDUCER AS | 1 | |
| 6V8940 | REDUCER-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 2350273 | 3 TUBE AS | 1 | |
| 2416220 | 4 CONNECTOR | 1 | |
| 3393497 | 5 HOSE AS | 1 | |
| 3209725 | 6 HOSE AS | 1 | |
| 8T6725 | 7 CONNECTOR | 1 | |
| 6V9849 | 8 ELBOW | 1 | |
| 2287102 | 9 SEAL-O-RING | 1 | |
| 2385082 | 10 SEAL-O-RING | 1 | |
| 6V4248 | 11 BOLT (M10X1.5X25-MM) | 2 | |
| 2287088 | 12 SEAL-O-RING | 2 | |
| 5P8245 | 13 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 6D3479 | 14 CLIP (LOOP) | 4 | |
| 8T0372 | 15 BOLT (M12X1.75X90-MM) | 1 | |
| 6V5839 | 18 WASHER (11X21X2.5-MM THK) | 8 | |
| 2287101 | 19 SEAL-O-RING | 1 | |
| 2287089 | 21 SEAL-O-RING | 1 | |
| 6V8556 | 22 NUT (1-3/16-12-THD) | 1 | |
| 6V9007 | 24 ELBOW | 1 | |
| 2287092 | 25 SEAL-O-RING | 1 | |
| 2Y5829 | 26 NUT (M10X1.5-THD) | 3 | |
| 3275216 | 27 CLIP (LOOP) | 1 | |
| 6V1820 | 28 BOLT (M10X1.5X30-MM) | 1 |
