System And Components
306-8902 LINES GP-ENGINE OILS/N ERM1-UP
Group No: 306-8902
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1294422 | 1 SPACER (13X25X64-MM THK) | 1 | |
| 2416220 | 2 CONNECTOR | 2 | |
| 2815941 | 3 CONNECTOR AS | 1 | |
| 8T7496 | CONNECTOR | 1 | |
| 2154639 | SEAL-O-RING | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 3393497 | 4 HOSE AS | 1 | |
| 3209712 | 5 HOSE AS | 1 | |
| 3209725 | 6 HOSE AS | 1 | |
| 2287102 | 9 SEAL-O-RING | 1 | |
| 2287088 | 11 SEAL-O-RING | 3 | |
| 5P8245 | 12 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 6D3479 | 13 CLIP (LOOP) | 4 | |
| 8T0372 | 14 BOLT (M12X1.75X90-MM) | 1 | |
| 6V5839 | 17 WASHER (11X21X2.5-MM THK) | 8 | |
| 2287101 | 18 SEAL-O-RING | 2 | |
| 2287089 | 20 SEAL-O-RING | 1 | |
| 2Y5829 | 22 NUT (M10X1.5-THD) | 3 | |
| 6V4248 | 23 BOLT (M10X1.5X25-MM) | 2 | |
| 3275216 | 24 CLIP (LOOP) | 1 | |
| 8T6725 | 25 CONNECTOR | 1 | |
| 6V9849 | 26 ELBOW | 1 | |
| 6V1820 | 27 BOLT (M10X1.5X30-MM) | 1 |
