System And Components
3G1731 TANK AND VALVE GROUP--Single Valve--Part 1Serial No. 15X1 to 15X956 inclusive
Group No: 3G1731
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7H1447 | 1 CAP | 1 | |
| 7B6368 | 2 BALL | 1 | |
| 6H5139 | 3 PLATE | 1 | |
| 9H6454 | 4 GASKET | 1 | |
| 3G0361 | 5 GASKET | 1 | |
| 9J3050 | 6 STRAINER ASSEM. | 1 | |
| 1D4717 | 7 NUT | 3 | |
| 5B9627 | WASHER | 3 | |
| 3B4506 | 8 LOCKWASHER | 42 | |
| 8J3571 | 9 COVER ASSEM. | 1 | |
| 9F2978 | 10 NUT | 29 | |
| 3H9523 | 11 GASKET | 1 | |
| 0L1351 | 12 BOLT 2.22 cm(.875 in.) long | 37 | |
| 9F2978 | 13 NUT | 4 | |
| 1A2029 | 14 BOLT | 5 | |
| 0S1595 | 15 BOLT | 2 | |
| 4J0816 | 16 ELEMENT ASSEM. (disposable) | 2 | |
| 2M8729 | 17 PIN | 1 | |
| 3J1997 | 18 RETAINER | 1 | |
| 7F9802 | 19 SPRING | 1 | |
| 5J1096 | 20 VALVE GROUP | 1 | |
| 5J1095 | 21 SEAT | 1 | |
| 9J8775 | 22 SPRING | 1 | |
| 3J1991 | 23 GASKET | 1 | |
| 4B7739 | 24 PLUG | 1 | |
| 7J5590 | 25 BOLT | 1 | |
| 8F9206 | 26 SEAL | 1 | |
| 4J0596 | 27 COVER | 1 | |
| 8M3494 | 28 PLATE (serial no.) | 1 | |
| 4B4158 | SCREW | 2 | |
| 3B4508 | 29 LOCKWASHER | 2 | |
| 8H9819 | 30 ADAPTER | 1 | |
| 8H9818 | GASKET | 1 | |
| 4J4382 | 31 PLUG | 1 | |
| 9S8004 | 32 PLUG | 1 | |
| 3J1907 | SEAL | 1 |
