System And Components
153-5104 DRIVE GP-FANS/N DK61-UP; DPZ1-UP
Group No: 153-5104
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7N8828 | 1 PULLEY-FAN DRIVE (4-GROOVE) | 1 | |
| 4N3123 | 2 ADAPTER-FAN | 1 | |
| 1F7960 | 3 WASHER (13.5X32X6-MM THK) | 4 | |
| 6N7688 | 4 BRACKET AS-FAN | 1 | |
| 1P9946 | 4A SHAFT-FAN | 1 | |
| 4N0684 | 4B DOWEL | 1 | |
| 8H9789 | 5 BALL BEARING | 1 | |
| 2D4867 | 6 FITTING-GREASE (1/8-27 PTF)(FAN DRIVE) | 1 | |
| 9F4446 | 7 SEAL-O-RING | 1 | |
| 3L1425 | 8 BALL BEARING | 1 | |
| 7N2900 | 9 RETAINER | 1 | |
| 5P7979 | 10 BOLT-LOCKING (5/16-24X2.25-IN) | 2 | |
| 8N5305 | 11 SPACER (35.6X47.62X43.74-MM THK) | 1 | |
| 7N8827 | 12 HUB | 1 | |
| 0L2070 | 13 BOLT (3/8-16X2.25-IN) | 6 | |
| 5S9062 | 14 SPACER (35.032X50.8X15.88-MM THK) | 1 | |
| 6N2547 | 15 ADAPTER-FAN BRACKET | 1 | |
| 9L4238 | 16 BOLT (3/8-16X8.5-IN) | 1 | |
| 9S8752 | 17 NUT-FULL (3/8-16-THD) | 1 | |
| 0S1594 | 18 BOLT (3/8-16X1-IN) | 2 | |
| 5M2894 | 19 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 1535625 | 20 V-BELT SET (INCLUDES 4-BELTS)(FAN DRIVE) | 1 | |
| 5S2106 | 21 SEAL-LIP TYPE | 1 | |
| 4B4550 | 22 FITTING-PRESSURE RELIEF (1/8-27 PTF) | 1 | |
| 6N2538 | 23 BRACKET-FAN ADJUSTMENT | 1 | |
| 9L0553 | 24 STUD-TAPERLOCK (1/2-13X4.25-IN) | 4 | |
| 1D4719 | 25 NUT-FULL (1/2-13-THD) | 4 |
