System And Components
204-0332 WIRING GP-ENGINES/N SPY1-UP
Group No: 204-0332
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1614 | 1 BOLT (1/4-20X0.5-IN) | 1 | |
| 5P6025 | 2 LOCKWIRE (0.8-M) | ||
| 4B9365 | 3 BOLT (1/4-20X3-IN) | 3 | |
| 8F8178 | 4 BOLT (1/4-20X3.25-IN) | 1 | |
| 4P8134 | 5 CLIP (LADDER) | 18 | |
| 7K1181 | 6 STRAP-CABLE | 19 | |
| 1A9579 | 7 BOLT (5/16-18X1.5-IN) | 4 | |
| 5P4116 | 8 WASHER-HARD (8.8X20.5X2-MM THK) | 6 | |
| 0T0102 | 9 BOLT (3/8-16X0.625-IN) | 1 | |
| 5M2894 | 10 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 4P7581 | 11 CLIP (LADDER) | 5 | |
| 1H3338 | 12 LOCKWASHER | 2 | |
| 9X9896 | 13 MOUNT (ISOLATION) | 8 | |
| 9S8750 | 14 NUT-FULL (1/4-20-THD) | 4 | |
| 7K1181 | 15 STRAP-CABLE | 5 | |
| 8S8158 | 16 SEAL-WIRE | 7 | |
| 4P7481 | 17 SPACER (6.6X25X21-MM THK) | 4 | |
| 1C0569 | 19 BOLT (5/16-18X0.5-IN) | 2 | |
| 7X6035 | 20 STRAP-GROUNDING | 1 | |
| 4B2043 | 21 NUT (8-32-THD) | 4 | |
| 2U9257 | 22 TUBE | 4 | |
| 3113019 | 23 HARNESS AS-ENGINE (IGNITION) | 1 | |
| 5P4115 | 24 WASHER-HARD (7.2X19X2-MM THK) | 9 | |
| 9X3495 | 25 CLIP AS | 1 | |
| 1940915 | 27 MOUNTING GP-CONTROL PANEL | 1 | |
| 0S1594 | 28 BOLT (3/8-16X1-IN) | 1 | |
| 0T0573 | 30 BOLT (3/8-16X2.75-IN) | 1 | |
| 4B4863 | 31 WASHER (4.7X11X1.2-MM THK) | 8 | |
| 8C8560 | 32 SCREW-LOCK (4-40X0.5-IN) | 4 | |
| 7R3029 | 33 CAP-DUST | 1 | |
| 3911756 | 34 WASHER (3.3X9.5X1.6-MM THK) | 8 | |
| 6B4540 | 35 NUT (4-40-THD) | 4 | |
| 1106197 | 36 GASKET | 1 | |
| 1957988 | 37 GASKET | 1 | |
| 9X8486 | 38 SCREW-MACHINE (8-32X0.75-IN) | 4 | |
| 7K3255 | 39 SPACER (0.59X0.88X0.28-IN THK) | 8 | |
| 0S1608 | 40 BOLT (3/8-16X3.75-IN) | 1 |
