System And Components
476-1951 LINES GP-AIRPART OF 443-1507 PNEUMATIC AR
Group No: 476-1951
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0617828 | 5 CONNECTOR | 1 | |
| 1L2283 | 12 ADAPTER | 2 | |
| 1Y8083 | 17 TEE-PIPE FLARED | 11 | |
| 2U3073 | 43 ADAPTER | 11 | |
| 3B9404 | 44 CONNECTOR | 36 | |
| 6V1739 | 45 TEE-PIPE REDUCING | 1 | |
| 0873400 | 46 ANGLE | 1 | |
| 3429555 | 47 GROMMET | 5 | |
| 3473917 | 48 VALVE AS-SOLENOID | 1 | |
| 3473920 | 49 MANIFOLD | 1 | |
| 3473921 | 50 VALVE AS-BALL | 1 | |
| 3636631 | 51 VALVE-CHECK | 7 | |
| 3680514 | 52 GASKET (1-IN) | 5 | |
| 3685261 | 53 CLAMP AS | 11 | |
| 3817110 | 54 SENSOR-PRESSURE (0 TO 1,000-KPA (0 TO 145-PSI)) | 1 | |
| 3874233 | 55 UNION | 1 | |
| 3897073 | 56 GASKET (5-IN) | 2 | |
| 4673542 | 57 ANGLE | 1 | |
| 4742601 | 58 ADAPTER-TEE | 7 | |
| 4742609 | 59 ADAPTER-TEE | 5 | |
| 4809541 | 60 BRACKET AS | 1 | |
| 8J6030 | NUT-WELD (3/8-16-THD) | 6 | |
| 8T5911 | NUT-WELD (1/2-13-THD) | 15 | |
| 4809542 | 61 BRACKET | 2 | |
| 4809543 | 62 BRACKET AS | 1 | |
| 4809544 | 63 BRACKET AS | 1 | |
| 8T5911 | NUT-WELD (1/2-13-THD) | 4 | |
| 4809545 | 64 BRACKET AS | 2 | |
| 8T5911 | NUT-WELD (1/2-13-THD) | 2 | |
| 4809564 | 65 BRACKET AS | 1 | |
| 8T5911 | NUT-WELD (1/2-13-THD) | 6 | |
| 4816096 | 66 TUBE AS | 1 | |
| 4816099 | 67 TUBE AS | 1 | |
| 4816100 | 68 TUBE AS | 1 | |
| 4817721 | 69 TUBE AS | 2 | |
| 4817722 | 70 TUBE AS | 1 | |
| 4817723 | 71 TUBE AS | 1 | |
| 4817724 | 72 TUBE AS | 1 | |
| 4817725 | 73 TUBE AS | 1 | |
| 4817726 | 74 TUBE AS | 1 | |
| 4817727 | 75 TUBE AS | 1 | |
| 4817728 | 76 TUBE AS | 1 | |
| 4817729 | 77 TUBE AS | 1 | |
| 4817730 | 78 TUBE AS | 1 | |
| 4817731 | 79 TUBE AS | 1 | |
| 4817732 | 80 TUBE AS | 1 | |
| 4817733 | 81 TUBE AS | 1 | |
| 4817734 | 82 TUBE AS | 1 | |
| 4817735 | 83 TUBE AS | 1 | |
| 4817736 | 84 TUBE AS | 1 | |
| 4817737 | 85 TUBE AS | 1 | |
| 4817739 | 86 TUBE AS | 1 | |
| 4817740 | 87 TUBE AS | 3 | |
| 4817741 | 88 TUBE AS | 1 | |
| 4817742 | 89 TUBE AS | 1 | |
| 4817743 | 90 TUBE AS | 1 | |
| 4817744 | 91 TUBE AS | 1 | |
| 4817745 | 92 TUBE AS | 1 | |
| 4817746 | 93 TUBE AS | 1 | |
| 4817747 | 94 TUBE AS | 1 | |
| 4817748 | 95 TUBE AS | 1 | |
| 4817749 | 96 TUBE AS | 1 | |
| 4817751 | 97 TUBE AS | 1 | |
| 4817752 | 98 TUBE AS | 1 | |
| 4817753 | 99 TUBE AS | 1 | |
| 4817754 | 100 TUBE AS | 1 | |
| 4817755 | 101 TUBE AS | 1 | |
| 4817756 | 102 TUBE AS | 1 | |
| 4817757 | 103 TUBE AS | 1 | |
| 4817758 | 104 TUBE AS | 1 | |
| 4817759 | 105 TUBE AS | 1 | |
| 4817760 | 106 TUBE AS | 1 | |
| 4817761 | 107 TUBE AS | 1 | |
| 4817762 | 108 TUBE AS | 1 | |
| 4817763 | 109 TUBE AS | 1 | |
| 4817764 | 110 TUBE AS | 1 | |
| 4817765 | 111 TUBE AS | 1 | |
| 4817766 | 112 TUBE AS | 1 | |
| 4817767 | 113 TUBE AS | 1 | |
| 4817768 | 114 TUBE AS | 1 | |
| 4817769 | 115 TUBE AS | 1 | |
| 4817770 | 116 TUBE AS | 1 | |
| 4817771 | 117 TUBE AS | 1 | |
| 4817772 | 118 TUBE AS | 1 | |
| 4817773 | 119 TUBE AS | 1 | |
| 4817774 | 120 TUBE AS | 1 | |
| 4817775 | 121 TUBE AS | 1 | |
| 4817776 | 122 TUBE AS | 1 | |
| 4817777 | 123 TUBE AS | 1 | |
| 4817778 | 124 TUBE AS | 1 | |
| 4817779 | 125 TUBE AS | 1 | |
| 4817780 | 126 PIPE AS | 1 | |
| 4817781 | 127 PIPE AS | 1 | |
| 4817782 | 128 PIPE AS | 1 | |
| 4817783 | 129 PIPE AS | 1 | |
| 4817784 | 130 PIPE AS | 1 | |
| 4817785 | 131 PIPE AS | 1 | |
| 4817786 | 132 TUBE AS | 1 | |
| 4817787 | 133 PIPE AS | 1 | |
| 4817788 | 134 PIPE AS | 1 | |
| 4817789 | 135 TUBE AS | 1 | |
| 4817790 | 136 PIPE AS | 1 | |
| 4817791 | 137 PIPE AS | 1 | |
| 4817792 | 138 PIPE AS | 1 | |
| 4817793 | 139 TUBE AS | 1 | |
| 4817794 | 140 TUBE AS | 1 | |
| 4817795 | 141 TUBE AS | 1 | |
| 4817796 | 142 TUBE AS | 1 | |
| 4817797 | 143 TUBE AS | 1 | |
| 4852884 | 144 VALVE | 1 | |
| 4861460 | 145 TUBE AS | 1 | |
| 4947054 | 146 PLATE | 1 | |
| 0032143 | 147 ELBOW | 2 | |
| 0039014 | 148 ELBOW | 5 | |
| 0039514 | 149 COUPLING-PIPE | 1 | |
| 0307765 | 150 FITTING | 2 | |
| 1307284 | 151 NIPPLE-PIPE | 2 | |
| 1362955 | 152 FITTING-PIPE | 1 | |
| 1F7958 | 153 NUT-FULL (1/2-13-THD) | 8 | |
| 1K6872 | 154 LOCKNUT (1/2-13-THD) | 2 | |
| 1Y7452 | 155 FITTING | 2 | |
| 2676786 | 156 FITTING | 1 | |
| 2D6235 | 157 LOCKNUT (1/4-20-THD) | 8 | |
| 2H0435 | 158 CLAMP | 2 | |
| 3888546 | 159 NUT | 2 | |
| 3B6496 | 160 ELBOW | 1 | |
| 3B9409 | 161 ELBOW-FLARED | 34 | |
| 4L7412 | 162 ADAPTER (PIPE) | 1 | |
| 4L9337 | 163 BOLT (3/8-16X1.5-IN) | 6 | |
| 4M5281 | 164 BOLT (1/4-20X0.75-IN) | 6 | |
| 5D1707 | 165 FITTING | 1 | |
| 5K0906 | 166 BOLT (5/16-18X0.625-IN) | 12 | |
| 5P2228 | 167 BOLT (1/2-13X1-IN) | 14 | |
| 5P4400 | 168 CONNECTOR | 2 | |
| 5P8245 | 169 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 5P8934 | 170 ELBOW | 1 | |
| 6B1628 | 171 BUSHING-REDUCER | 2 | |
| 6B4661 | 172 BUSHING-REDUCER | 2 | |
| 7D1649 | 173 WASHER-HARD (13.5X32X5-MM THK) | 8 | |
| 7E2707 | 174 CLIP | 1 | |
| 7F6654 | 175 NIPPLE-PIPE | 1 | |
| 7M7410 | 176 PLUG-PIPE | 7 | |
| 7X0347 | 177 BOLT (5/8-11X2.25-IN) | 10 | |
| 8B3308 | 178 FITTING | 1 | |
| 8S5088 | 179 WASHER (15.44-MM THK) | 10 | |
| 8T2502 | 180 BOLT (3/8-16X1.125-IN) | 2 | |
| 8T4188 | 181 ADAPTER-UNION | 2 | |
| 8T4205 | 182 WASHER-HARD (7.2X14.5X2-MM THK) | 16 | |
| 8T4224 | 183 WASHER-HARD (8.8X16X2-MM THK) | 20 | |
| 8T4896 | 184 WASHER-HARD (10.2X18.5X2.5-MM THK) | 10 | |
| 8T5360 | 185 WASHER (12X22.5X2.5-MM THK) | 43 | |
| 8T8908 | 186 BOLT (1/4-20X1-IN) | 8 | |
| 8T8917 | 187 BOLT (1/2-13X1.25-IN) | 25 | |
| 8T8919 | 188 BOLT (1/2-13X1.75-IN) | 20 | |
| 8T9043 | 189 BOLT (5/16-18X0.875-IN) | 2 | |
| 8T9384 | 190 BOLT (1/2-13X0.875-IN) | 4 | |
| 9F6343 | 191 CLAMP | 12 | |
| 1417298 | 193 PIPE (44-CM) | ||
| 1731861 | 194 PIPE (45-CM) |
