System And Components
3N-8888 HEAT EXCHANGER GP-SEA WATERS/N LNW1-UP
Group No: 3N-8888
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5L9128 | 1 ROD AS-ZINC (HEAT EXCHANGER) | 3 | |
| 6L2286 | 1A PLUG-PIPE | 1 | |
| 6L2284 | 1B ROD-ZINC | 1 | |
| 2W4875 | 2 BRACKET AS | 2 | |
| 3N9610 | 3 BONNET | 1 | |
| 3N9626 | 4 SHELL AS | 1 | |
| 6L2279 | 5 PLUG-PIPE | 4 | |
| 6L2282 | 6 PLUG-PIPE | 2 | |
| 7L0487 | 7 GASKET | 1 | |
| 8L4952 | 8 GASKET | 1 | |
| 8L4955 | 9 BONNET-RETURN | 1 | |
| 8L9767 | 10 SHIM (0.015-IN THK) | 48 | |
| 2930007 | 11 CORE AS (HEAT EXCHANGER) | 1 | |
| 0T0320 | 12 BOLT (7/16-14X1.25-IN) | 12 | |
| 0T0768 | 13 BOLT (7/16-14X1.75-IN) | 12 | |
| 1H1200 | 14 PIN-SPRING | 1 | |
| 3B4506 | 15 LOCKWASHER | 4 | |
| 3B4507 | 16 LOCKWASHER | 24 | |
| 3N9606 | 17 U-BOLT | 2 | |
| 7L0486 | 18 SEAL-RUBBER | 1 | |
| 9S8752 | 19 NUT-FULL (3/8-16-THD) | 4 |
