System And Components
359-5245 COOLER GP-TRANSMISSION OILS/N NGH1-UP
Group No: 359-5245
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2S0795 | 1 GASKET | 2 | |
| 8M9307 | 2 PLUG | 1 | |
| 8S4304 | 3 BONNET-XMSN OIL COOLER | 1 | |
| 1803907 | 4 SEAL-INTEGRAL | 1 | |
| 1873523 | 5 CORE AS-OIL COOLER (TRANSMISSION) | 1 | |
| 8T6764 | PLUG-PIPE (1/8-27-THD) | 1 | |
| 1983462 | 6 DIVERTER | 1 | |
| 3485792 | 7 BRACKET | 1 | |
| 3571098 | 8 BONNET-OIL COOLER | 1 | |
| 1364189 | 9 BOLT (M12X1.75X75-MM) | 6 | |
| 1608748 | 10 BOLT (M12X1.75X55-MM) | 2 | |
| 6F7062 | 11 WASHER (12.7X19.05X1.83-MM THK) | 1 | |
| 6V3668 | 13 BOLT (M12X1.75X30-MM) | 4 | |
| 6V8675 | 15 BOLT (M12X1.75X35-MM) | 1 | |
| 7D1649 | 16 WASHER-HARD (13.5X32X5-MM THK) | 3 | |
| 7X2543 | 17 BOLT (M10X1.5X120-MM) | 2 | |
| 8T6854 | 18 BOLT (M10X1.5X200-MM) | 4 | |
| 3960403 | 19 PLUG AS | 1 | |
| 3603679 | PLUG-CONNECTOR (9/16-18-THD) | 1 | |
| 6V3250 | 19A SEAL-O-RING | 1 | |
| 3960405 | 20 PLUG AS | 1 | |
| 3603680 | PLUG (3/4-16-THD) | 1 | |
| 6V6609 | SEAL-O-RING | 1 |
