397-1834 COOLER GP-TRANSMISSION OILS/N NGH1-UP
Group No: 397-1834
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2S0795 | 1 GASKET | 2 | |
| 8M9307 | 2 PLUG | 1 | |
| 8S4304 | 3 BONNET-XMSN OIL COOLER | 1 | |
| 1275537 | 4 CORE AS | 1 | |
| 1803907 | 5 SEAL-INTEGRAL | 1 | |
| 1983462 | 6 DIVERTER | 1 | |
| 3294028 | 7 BONNET | 1 | |
| 3960403 | 8 PLUG AS | 1 | |
| 6V3250 | SEAL-O-RING | 1 | |
| 3603679 | PLUG-CONNECTOR (9/16-18-THD) | 1 | |
| 3960405 | 9 PLUG AS | 1 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 3603680 | PLUG (3/4-16-THD) | 1 | |
| 3985614 | 10 PLUG AS | 1 | |
| 6V5064 | SEAL-O-RING | 1 | |
| 3603684 | PLUG | 1 | |
| 4337085 | 11 MOUNTING GP | 1 | |
| 0S1595 | 12 BOLT (1/2-13X1.25-IN) | 4 | |
| 9X8874 | 13 BOLT (1/2-13X3-IN) | 2 | |
| 9X8873 | 14 BOLT (1/2-13X2.25-IN) | 4 | |
| 6F7062 | 15 WASHER (12.7X19.05X1.83-MM THK) | 1 | |
| 8T9085 | 16 BOLT (M10X1.5X150-MM) | 3 | |
| 8T0644 | 17 BOLT (M10X1.5X90-MM) | 3 |
