System And Components
3N-8166 SHUTOFF GP-AIR24/32 VOLT
Group No: 3N-8166
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1594 | 1 BOLT (3/8-16X1-IN) | 2 | |
| 6F0612 | 3 NUT-JAM (1/4-28-THD) | 1 | |
| 3N7848 | 4 SPRING | 1 | |
| 1W9070 | 5 DIODE AS | 1 | |
| 4F7957 | 6 BOLT (1/4-20X0.875-IN) | 2 | |
| 1082858 | 8 SPRING | 1 | |
| 3N7967 | 9 SHAFT | 1 | |
| 1Y0462 | 10 WASHER (0.328X0.81X0.125-IN THK) | 3 | |
| 4L8337 | 11 SEAL-O-RING | 2 | |
| 3N8165 | 12 PIPE | 1 | |
| 5N3160 | 13 STUD (1/4-20X2-IN) | 1 | |
| 3N7825 | 14 LATCH | 1 | |
| 1B4330 | 15 NUT (1/4-20-THD) | 1 | |
| 5P0537 | 16 WASHER-HARD (7.2X14.5X2-MM THK) | 3 | |
| 5H1190 | 17 SEAL-LIP TYPE | 1 | |
| 4N2883 | 18 SHAFT-SHUTOFF | 1 | |
| 4N2882 | 19 VALVE AS | 1 | |
| 1C0569 | 20 BOLT (5/16-18X0.5-IN) | 2 | |
| 9S5282 | 21 WASHER-HARD (8.8X14.5X2-MM THK) | 2 | |
| 3N8084 | 22 DIODE AS | 1 | |
| 9B7242 | 23 SCREW-MACHINE (8-32X0.31-IN) | 1 | |
| 4B2043 | 24 NUT (8-32-THD) | 1 | |
| 5S1188 | 25 SEAL-O-RING | 2 | |
| 5N3129 | 26 BRACKET | 1 | |
| 4N3890 | 27 SOLENOID AS (24-VOLT)(AIR SHUTOFF) | 1 | |
| 6V8362 | SCREW-MACHINE (8-32X0.31-IN) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 3N9137 | 28 BLOCK AS | 1 | |
| 5H5744 | BUSHING-TERMINAL | 1 | |
| 5M2894 | 29 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 5N3852 | 30 BEARING | 2 |
