System And Components
3N-8029 CONTROL GP-GOVERNORAIR ACTUATED
Group No: 3N-8029
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0617284 | 1 ROD | 1 | |
| 6V8186 | 2 NUT-FULL (5/16-24-THD) | 2 | |
| 3D5878 | 3 ROD END | 1 | |
| 2A4133 | 4 PIN | 2 | |
| 3B4607 | PIN-COTTER | 2 | |
| 5N3220 | 5 ACTUATOR GP-AIR | 1 | |
| 3N9435 | 6 PLATE | 1 | |
| 6V8801 | 7 NUT (3/8-16-THD) | 2 | |
| 8T4896 | 8 WASHER-HARD (10.2X18.5X2.5-MM THK) | 12 | |
| 5N3022 | 9 BRACKET AS (L.H.) | 1 | |
| 5N3030 | BRACKET AS (R.H.) | 1 | |
| 4L6454 | 10 BOLT (3/8-16X1-IN) | 4 | |
| 5S7382 | 11 BOLT (3/8-16X1.375-IN) | 2 | |
| 4F1001 | 12 END-YOKE | 1 | |
| 3N9454 | 13 LEVER | 1 | |
| 1H3337 | 14 BOLT (1/4-20X0.875-IN) | 2 | |
| 6V8185 | NUT (1/4-20-THD) | 2 | |
| 3B4504 | LOCKWASHER | 2 | |
| 6J6478 | WASHER (0.28X0.63X0.13-IN THK) | 2 | |
| 8T2501 | 15 BOLT (3/8-16X2-IN) | 4 | |
| 1A9579 | 16 BOLT (5/16-18X1.5-IN) | 6 | |
| 1D4716 | NUT-FULL (5/16-18-THD) | 6 | |
| 3B4505 | LOCKWASHER | 6 | |
| 8T9377 | 17 BOLT (3/8-16X2.25-IN) | 4 | |
| 6B0933 | SPACER (10.31X19.05X6.35-MM THK) | 2 |
