System And Components
4N-0957 STARTING MOTOR GP-ELECTRIC24 VOLT
Group No: 4N-0957
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7F4556 | 1 BOLT | 4 | |
| 1L4789 | 2 LOCKWASHER | 4 | |
| 4M1844 | 3 FRAME AS-END | 1 | |
| 7S9826 | 4 PLUG-EXPANSION | 1 | |
| 9G4100 | 5 BUSHING-END | 1 | |
| 2B4602 | 6 PLUG-PIPE | 1 | |
| 9F2547 | 7 WICK (1/2-13 THD) | 1 | |
| 2L8166 | 8 WASHER | 1 | |
| 4M1868 | 9 ARMATURE AS | 1 | |
| 3L3380 | 10 BUSHING-TERMINAL | 1 | |
| 4M1839 | 11 COIL AS-FIELD | 1 | |
| 9H3757 | 12 WASHER (0.516X1X0.094-IN THK) | 2 | |
| 7F3494 | 13 WASHER (13.1X22.4X.8-MM THK) | 1 | |
| 4M1841 | 14 CONNECTOR | 1 | |
| 1D5117 | 15 NUT-JAM (1/2-13-THD) | 2 | |
| 3T3421 | 16 SOLENOID AS-STARTING MOTOR | 1 | |
| 6H3622 | 17 SCREW-MACHINE (1/4-20X0.5-IN) | 4 | |
| 3B4508 | 18 LOCKWASHER | 1 | |
| 3F0379 | 19 SCREW-POLE SHOE (3/8-24-THD) | 8 | |
| 2N3145 | 20 INSULATOR | 1 | |
| 4M1831 | 21 PLUG-LEVER HOUSING | 2 | |
| 4M1832 | 22 GASKET-PLUG | 2 | |
| 1H2629 | 23 STRIP-INSULATION | 2 | |
| 8H1141 | 24 SHOE-POLE | 4 | |
| 4M1849 | 25 LEAD AS | 1 | |
| 4M0189 | 26 SEAL-O-RING | 1 | |
| 7F3529 | 27 WASHER | 3 | |
| 8H0878 | 28 LOCKWASHER | 3 | |
| 4B1220 | 29 SCREW-MACHINE (8-32X0.375-IN) | 3 | |
| 4M1846 | 30 PLATE AS-BRUSH | 1 | |
| 7F3525 | 31 WASHER-SPECIAL (0.207X0.39X0.09-IN THK) | 8 | |
| 7F4550 | 32 PLATE-HOLDER | 1 | |
| 5H6467 | 33 SCREW-MACHINE | 2 | |
| 7H2079 | 34 LOCKWASHER | 8 | |
| 2L6679 | 35 PLATE-INSULATOR | 2 | |
| 7F4546 | 36 HOLDER-BRUSH | 4 | |
| 7F3522 | 37 SCREW-HOLDER | 2 | |
| 7F3512 | 38 SPRING | 8 | |
| 7F4549 | 39 PLATE-HOLDER | 2 | |
| 4B1311 | 40 SCREW-MACHINE | 2 | |
| 7F4545 | 41 PLATE-BRUSH | 1 | |
| 3H3697 | 42 SCREW (1/2-13 THD) | 2 | |
| 1D4719 | 43 NUT-FULL (1/2-13-THD) | 1 | |
| 2F2860 | 44 SCREW-MACHINE (8-32X7.94-MM) | 8 | |
| 3B4501 | LOCKWASHER | 8 | |
| 4M1845 | 45 BRUSH AS | 8 | |
| 7F3491 | 46 WASHER (0.516X1X0.094-IN THK) | 2 | |
| 1D5117 | 47 NUT-JAM (1/2-13-THD) | 1 | |
| 7F3494 | 48 WASHER (13.1X22.4X.8-MM THK) | 1 | |
| 3B4508 | 49 LOCKWASHER | 2 | |
| 9M7611 | 50 RING-RETAINING | 2 | |
| 9M7606 | 51 PLUNGER AS | 1 | |
| 4M0188 | 52 WASHER | 1 | |
| 4M1829 | 53 BOOT-RUBBER (9.25MM ID) | 1 | |
| 4M1828 | 54 RETAINER-SPRING | 1 | |
| 9M7609 | 55 SPRING (SHIFT LEVER) | 1 | |
| 4M1827 | 56 RETAINER-SPRING | 1 | |
| 1H1023 | 57 SEAL-O-RING | 1 | |
| 3T5046 | 58 HOUSING AS-LEVER | 1 | |
| 9F2547 | 59 WICK | 1 | |
| 2B4602 | 60 PLUG-PIPE | 1 | |
| 1M9968 | 61 BUSHING | 1 | |
| 2F6678 | 62 SEAL-LIP TYPE | 1 | |
| 4L2729 | 63 WASHER (0.844X1.9X0.188-IN THK) | 1 | |
| 4L2729 | 64 WASHER (0.844X1.9X0.188-IN THK) | 1 | |
| 4M1853 | 65 LEVER AS-SHIFT | 1 | |
| 3F2617 | 66 LOCKNUT (5/16-24-THD) | 1 | |
| 7L2894 | 67 GASKET | 1 | |
| 4M1831 | 68 PLUG-LEVER HOUSING | 1 | |
| 1S0297 | 69 HOUSING AS-DRIVE | 1 | |
| 4M1896 | 70 BUSHING-TERMINAL | 1 | |
| 4M1833 | 71 SCREW (5/16-18X1.5-IN) | 5 | |
| 7M0336 | SCREW (5/16-18X0.859-IN) | 1 | |
| 6N3826 | 72 DRIVE AS-MOTOR | 1 | |
| 1P2508 | DRIVE AS-MOTOR | 1 | |
| 9S9774 | 73 PINION-DRIVE | 1 | |
| 4M1854 | 74 SHAFT-LEVER | 1 | |
| 2D6392 | 75 SEAL-O-RING | 1 | |
| 7F4556 | 76 BOLT | 5 | |
| 1L4789 | 77 LOCKWASHER | 5 | |
| 4M0189 | 78 SEAL-O-RING | 1 | |
| 1M9971 | 79 SPACER (0.835X1.72X0.188-IN THK) | 1 | |
| 4M1851 | 80 GASKET | 1 | |
| 7N6098 | KIT-SPRING CUP | 1 | |
| 4S9459 | KIT-WASHER | 1 | |
| 3N3763 | KIT-TERMINAL (STARTING MOTOR) | 1 |
