System And Components
9N-3755 PUMP GP-GOV & FUEL INJAN ATTACHMENT
Group No: 9N-3755
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4N0209 | 1 BONNET-VALVE | 8 | |
| 9L9424 | 2 SPRING-VALVE | 8 | |
| 9B1320 | VALVE-CHECK | 8 | |
| 4N0218 | 3 BUSHING-TERMINAL | 8 | |
| 6N7527 | 4 PUMP AS-FUEL INJECTION | 8 | |
| 4N2728 | 5 WASHER-RETAINING | 1 | |
| 9N5862 | 6 SPRING-LIFTER | 1 | |
| 4N2685 | 7 ROLLER-LIFTER | 8 | |
| 6N6794 | 8 LIFTER-PLUNGER | 8 | |
| 4N0224 | 9 RING-RETAINING | 8 | |
| 6F6672 | 10 SEAL-O-RING | 8 | |
| 4N2773 | 11 SHAFT AS-CONTROL | 1 | |
| 1D4716 | 12 NUT-FULL (5/16-18-THD) | 1 | |
| 4N2708 | 13 SETSCREW | 1 | |
| 4N0528 | 14 SHAFT-LEVER | 1 | |
| 4N9828 | 15 SHAFT AS-CONTROL | 1 | |
| 4N3922 | 16 LEVER AS | 1 | |
| 2N2658 | 17 BOLT-SOCKET HEAD (8-32X15.88-MM) | 10 | |
| 4N1763 | 18 LEVER-CONTROL | 8 | |
| 4N0563 | 19 LEVER-SHAFT | 1 | |
| 9L6807 | 20 SHAFT-CONTROL | 1 | |
| 4N1809 | 21 LEVER AS-SEAT | 1 | |
| 0310214 | 22 BOLT-LOCKING (1/4-20X0.5-IN) | 2 | |
| 9M1311 | 23 NUT-JAM (1/4-28-THD) | 1 | |
| 6N4176 | 24 SETSCREW | 1 | |
| 4N0445 | 25 LEVER-LOAD STOP | 1 | |
| 4N0523 | 26 DOWEL-STOP SUPPORT | 2 | |
| 2D6392 | 27 SEAL-O-RING | 2 | |
| 4N3329 | 28 WASHER (16.25X25.65X0.79-MM) | 2 | |
| 6N7523 | 29 WASHER (6.48X11.9X1.57-MM THK) | 1 | |
| 8F8178 | 30 BOLT (1/4-20X3.25-IN) | 1 | |
| 1D4533 | 31 BOLT (1/4-20X2.25-IN) | 3 | |
| 2A4781 | 32 BOLT (1/4-20X2.75-IN) | 3 | |
| 8N3946 | 33 HOUSING AS-GOVERNOR | 1 | |
| 4N2333 | 34 PIN-SPRING | 1 | |
| 8S6814 | 35 PIN | 2 | |
| 9L9503 | 36 DOWEL-HOLLOW | 1 | |
| 9S4182 | 37 PLUG (7/16-20-THD) | 1 | |
| 3J7354 | 38 SEAL-O-RING | 1 | |
| 8N3945 | 39 BUSHING-TERMINAL | 1 | |
| 4N2786 | 40 SEAL-LIP TYPE | 1 | |
| 4N2677 | 41 LEVER AS-RISER | 1 | |
| 3H0442 | 42 SEAL-O-RING | 1 | |
| 2M7819 | 43 RING-RETAINING | 1 | |
| 0S1615 | 44 BOLT (1/4-20X0.75-IN) | 7 | |
| 3J7354 | 45 SEAL-O-RING | 1 | |
| 9S4182 | 46 PLUG (7/16-20-THD) | 1 | |
| 8H3127 | 47 BOLT (1/4-20X0.75-IN) | 2 | |
| 9S9332 | 48 FITTING-ELBOW | 1 | |
| 6N1729 | 49 COVER-PUMP HOUSING | 1 | |
| 6D3031 | 50 SCREW-SOCKET HEAD (8-32X0.375-IN) | 4 | |
| 4N0941 | 51 LEVER-LIMITER | 1 | |
| 4N0505 | 52 GASKET-HOUSING | 1 | |
| 4N0935 | 53 HOUSING AS (SHUT-OFF) | 1 | |
| 4N3713 | SEAL-LIP TYPE | 1 | |
| 4N0595 | 54 GASKET-TOP COVER | 1 | |
| 9N3754 | 55 HOUSING AS-PUMP | 1 | |
| 4N5050 | PLUG | 1 | |
| 4N9150 | 56 DEFLECTOR-PULSE | 1 | |
| 4N1826 | 57 DOWEL | 2 | |
| 2D6392 | 58 SEAL-O-RING | 2 | |
| 6N1078 | 59 BEARING | 1 | |
| 4N3711 | 60 BUSHING | 1 | |
| 4N2333 | 61 PIN-SPRING | 1 | |
| 8N0984 | 62 PIN-SPRING | 8 | |
| 4N5481 | 63 STUD | 1 | |
| 1P4001 | 64 FITTING | 1 | |
| 4N0556 | 65 GASKET-GOVERNOR HOUSING | 1 | |
| 4N0532 | 66 GASKET-COVER | 1 | |
| 4N0531 | 67 COVER-IDLE SCREW | 1 | |
| 6L1756 | 68 BOLT (1/4-20X1.5-IN) | 2 | |
| 4N0938 | 69 SHAFT-LEVER | 1 | |
| 4N0940 | 70 LEVER-SHUTOFF | 1 | |
| 4N0937 | 71 SHAFT-LEVER | 1 | |
| 7N1359 | 72 FLANGE | 1 | |
| 2M5471 | 73 BOLT | 2 | |
| 4N3088 | 74 GASKET-INLET | 1 | |
| 6N1716 | 75 VALVE AS | 1 | |
| 3J7354 | 76 SEAL-O-RING | 1 | |
| 9F6641 | 77 BOLT (5/16-18X1.25-IN) | 4 | |
| 4N2954 | 78 SLEEVE-CAMSHAFT | 1 | |
| 4N1132 | 79 BODY AS-TRANSFER PUMP | 1 | |
| 8S6814 | 80 PIN | 1 | |
| 4N1584 | 81 SEAL-LIP TYPE | 1 | |
| 4N0636 | 82 SEAL-LIP TYPE | 1 | |
| 8H9804 | 83 SHAFT-PUMP IDLER | 1 | |
| 4N0429 | 84 GEAR-PUMP (15-TEETH) | 1 | |
| 4N0406 | 85 GEAR-PUMP (10-TEETH) | 1 | |
| 5M6509 | 86 SEAL-O-RING | 1 | |
| 4N1767 | 87 VALVE-BYPASS | 1 | |
| 4N0605 | 88 SPRING | 1 | |
| 4N0975 | 89 GASKET-CHECK VALVE | 1 | |
| 7N1364 | 90 FLANGE AS-CHECK VALVE | 1 | |
| 1P2298 | 91 VALVE AS | 1 | |
| 4N4276 | 92 SEAT-SPRING | 1 | |
| 4N6408 | 93 PISTON AS | 1 | |
| 4N6406 | 94 RING-SPACER | 1 | |
| 4N6404 | 95 RING-RETAINING | 1 | |
| 4N6407 | 96 SPOOL-DASHPOT | 1 | |
| 6N2517 | 97 SPRING-DASHPOT | 1 | |
| 4N5579 | 98 SEAT AS-SPRING | 1 | |
| 4N0434 | 99 RISER-GOVERNOR | 1 | |
| 4N2927 | 100 RACE-THRUST BEARING | 2 | |
| 4N2401 | BEARING-THRUST | 1 | |
| 4N2953 | 101 RING-LOCK | 1 | |
| 4N3779 | 102 KEY-CAMSHAFT | 1 | |
| 9N3751 | 103 CAMSHAFT-FUEL PUMP | 1 | |
| 8N2663 | 104 CARRIER-WEIGHT | 1 | |
| 8N2662 | 105 BOLT-SOCKET HEAD | 3 | |
| 4N1723 | 106 SHIELD-CARRIER | 1 | |
| 4N0425 | 107 WEIGHT-GOVERNOR | 3 | |
| 4N0511 | 108 DOWEL | 3 | |
| 4N5482 | 109 SHAFT-WEIGHT CARRIER | 1 | |
| 4N9019 | 110 DOWEL | 1 |
