Assembly
100%

7E-0430 COOLER GP-TRANSMISSION OILFOR USE WITH ATAAC ENGINES WITH TRANSMISSION IN THE NARROW OR 91 TRUCK FRAMES

Group No: 7E-0430
Part NumberPart NameQty
5M47411 GASKET2
2W99782 CORE AS-OIL COOLER1
5S71633 BONNET1
6I09224 BRACKET-MOUNTING1
8F44425 LOCK-CAGE NUT2
5M28946 WASHER-HARD (10.2X18.5X2.5-MM THK)23
1A20297 BOLT (3/8-16X1.125-IN)8
9X64588 WASHER-HARD (10.2X22.5X3-MM THK)2
3B19159 BOLT (3/8-16X1.375-IN)8
0S159410 BOLT (3/8-16X1-IN)3
4J052011 SEAL-O-RING2
4V153312 FLANGE2
6F706213 WASHER (12.7X19.05X1.83-MM THK)1
8M930714 PLUG1
0S159115 BOLT (3/8-16X1.5-IN)2
9S875216 NUT-FULL (3/8-16-THD)4
0S158817 BOLT (3/8-16X1.25-IN)4
5S805518 GASKET1
4N384119 GASKET1
4N384020 COVER1
9M197421 WASHER-HARD (8.8X16X2-MM THK)2
0S1617BOLT (5/16-18X0.75-IN)2
1F473822 GASKET1
6B004123 COVER1
0S050924 BOLT (3/8-16X0.75-IN)2
2W456125 GASKET1
8S540926 GASKET1
7N583327 BONNET-OIL COOLER1
7X773128 PLUG-PIPE (3/4-14-THD)1
9L509429 ELBOW-FLARED1
7N452030 CLAMP1
