System And Components
7N-6045 COOLER GP-TRANSMISSION OILFOR USE WITH 7N-6588, TURBOCHARGED AFTERCOOLED ENGINE
Group No: 7N-6045
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8S5409 | 1 GASKET | 1 | |
| 7N5833 | 2 BONNET-OIL COOLER | 1 | |
| 0S1617 | 3 BOLT (5/16-18X0.75-IN) | 2 | |
| 9M1974 | WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 4N3840 | 4 COVER | 1 | |
| 4N3841 | GASKET | 1 | |
| 5M4741 | 5 GASKET | 2 | |
| 0S1588 | 6 BOLT (3/8-16X1.25-IN) | 4 | |
| 2W9978 | 7 CORE AS-OIL COOLER (TRANSMISSION) | 1 | |
| 7N4520 | 8 CLAMP | 1 | |
| 1A2029 | 9 BOLT (3/8-16X1.125-IN) | 8 | |
| 5S7163 | 10 BONNET | 1 | |
| 8M9307 | 11 PLUG | 1 | |
| 6F7062 | WASHER (12.7X19.05X1.83-MM THK) | 1 | |
| 4V1533 | 12 FLANGE | 2 | |
| 4J0520 | SEAL-O-RING | 2 | |
| 3B1915 | 13 BOLT (3/8-16X1.375-IN) | 8 | |
| 5M2894 | 14 WASHER-HARD (10.2X18.5X2.5-MM THK) | 23 | |
| 0S1591 | 15 BOLT (3/8-16X1.5-IN) | 2 | |
| 8N4049 | 16 BRACKET AS-MOUNTING | 1 | |
| 5S8055 | 17 GASKET | 1 | |
| 0S1594 | 18 BOLT (3/8-16X1-IN) | 3 | |
| 3J5390 | 19 PLUG (3/8-18-THD) | 1 | |
| 1B5174 | 20 PLUG-PIPE | 1 | |
| 2W4561 | 21 GASKET | 1 | |
| 5L2952 | 22 CAP AS-FILLER (TRANSMISSION OIL) | 1 | |
| 8F4442 | 23 LOCK-CAGE NUT | 2 | |
| 1D4717 | 24 NUT (3/8-16-THD) | 4 |
