System And Components
9Y-9943 AIR COMPRESSOR GP12 CFM AT 1250 RPM. TU-FLO 501
Group No: 9Y-9943
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2P4358 | 1 FLANGE | 1 | |
| 6D1004 | 2 GASKET | 1 | |
| 6N5876 | 3 GASKET-FRONT COVER | 2 | |
| 0S0509 | 4 BOLT (3/8-16X0.75-IN) | 6 | |
| 3B4506 | 5 LOCKWASHER | 6 | |
| 6I2121 | 6 CYLINDER HEAD GP | 1 | |
| 6V1820 | 7 BOLT (M10X1.5X30-MM) | 2 | |
| 6V5839 | 8 WASHER (11X21X2.5-MM THK) | 2 | |
| 6N2098 | 9 GASKET-CYLINDER HEAD | 1 | |
| 6N6949 | 10 COVER-CRANKCASE | 1 | |
| 6I2122 | 11 RETAINER | 2 | |
| 6N0634 | 12 GASKET-COVER | 1 | |
| 8T9522 | 13 SEAL-O-RING | 2 | |
| 7N4837 | PISTON AS-COMPRESSOR | 2 | |
| 1W2803 | PLUG | 2 | |
| 6I1219 | KIT-REPAIR (AIR COMPRESSOR) | 1 | |
| 6I1220 | KIT-UNLOADER (AIR COMPRESSOR)(AIR COMPRESSOR) | 1 | |
| 6N2109 | KIT-PISTON RING (AIR COMPRESSOR) | 1 |
