System And Components
272-3252 LINES GP-CENTRAL LUBRICATIONS/N LAJ492-534
Group No: 272-3252
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8X8474 | 1 HOSE AS | 2 | |
| 1447901 | 2 HOSE AS | 1 | |
| 1488424 | 3 TEE AS | 1 | |
| 8T8902 | ADAPTER-TEE | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1590994 | 4 HOSE AS | 2 | |
| 3494591 | 5 PLATE | 1 | |
| 1952640 | 6 BRACKET | 3 | |
| 1976355 | 7 ELBOW AS | 1 | |
| 3E7449 | ELBOW | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 2188326 | 8 HOSE AS | 2 | |
| 3784329 | 9 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 14 | |
| 7T1099 | LINK | 3 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 3 | |
| 9R2672 | BOSS-THREADED (M10X1.5X20-MM) | 4 | |
| 9R2613 | BOSS-WELD (M10X1.5X25-MM) | 1 | |
| 0908247 | BLOCK (M10X1.5-MM) | 1 | |
| 2919654 | 10 PLATE | 2 | |
| 2929076 | 11 PLATE AS | 1 | |
| 9R2672 | BOSS-THREADED (M10X1.5X20-MM) | 1 | |
| 2932700 | 12 HOSE AS | 1 | |
| 2932706 | 13 HOSE AS | 1 | |
| 2937514 | 14 HOSE AS | 2 | |
| 2937549 | 15 HOSE AS | 2 | |
| 3084280 | 16 PLATE AS | 1 | |
| 3230208 | 17 HOSE AS | 2 | |
| 3348714 | 18 HOSE AS | 1 | |
| 3348715 | 19 HOSE AS | 1 | |
| 3348716 | 20 HOSE AS | 2 | |
| 3356128 | 21 HOSE AS | 1 | |
| 3731104 | 22 HOSE AS | 1 | |
| 1197724 | 24 HOSE AS | 1 | |
| 3440997 | 25 HOSE AS | 1 | |
| 0046683 | 26 FITTING | 3 | |
| 1488320 | 27 CONNECTOR AS | 7 | |
| 8C6865 | CONNECTOR | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 1488389 | 28 ELBOW AS | 30 | |
| 7X0492 | ELBOW | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 1488427 | 29 TEE AS | 1 | |
| 8T6895 | TEE-UNION | 1 | |
| 6V8398 | SEAL-O-RING | 3 | |
| 1488444 | 30 TEE AS-SWIVEL | 1 | |
| 6V9837 | TEE-SWIVEL | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 7C8246 | 31 SPACER (10.5X20X24-MM THK) | 2 | |
| 1997854 | 32 SPACER (11.8X20X45-MM THK) | 1 | |
| 1S0994 | 33 CLIP (LOOP) | 17 | |
| 2R1939 | 34 CLIP (LOOP) | 10 | |
| 2T2396 | 35 ELBOW | 2 | |
| 3J5390 | 36 PLUG (3/8-18-THD) | 3 | |
| 4D6466 | 37 CLIP | 11 | |
| 4J5477 | 38 SEAL-O-RING | 2 | |
| 4K8864 | 39 CLIP (LOOP) | 43 | |
| 4S6668 | 40 CLIP (LOOP) | 7 | |
| 5H7598 | 41 NIPPLE-PIPE | 2 | |
| 5M6213 | 42 PLUG-PIPE (1/4-18-THD) | 1 | |
| 5P4295 | 43 CLIP | 1 | |
| 5P7462 | 44 CLIP (SLOT) | 5 | |
| 5P7463 | 45 CLIP (TAB) | 5 | |
| 5P7470 | 46 CLIP (SLOT) | 1 | |
| 5P7471 | 47 CLIP (TAB) | 1 | |
| 5P7703 | 48 GROMMET (52-MM ID) | 1 | |
| 5T6374 | 49 SPACER (11X20X40-MM THK) | 3 | |
| 6K6967 | 50 ADAPTER-PIPE | 2 | |
| 6V0683 | 51 GROMMET | 5 | |
| 6V8398 | 53 SEAL-O-RING | 2 | |
| 6V9169 | 54 NUT (13/16-16-THD) | 1 | |
| 6V9828 | 55 CAP (ORFS) | 1 | |
| 2032059 | 57 CONNECTOR AS | 1 | |
| 8C6869 | CONNECTOR | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8R0721 | 58 SPACER (11X16X35-MM THK) | 2 | |
| 8T4121 | 59 WASHER-HARD (11X21X2.5-MM THK) | 101 | |
| 8T4133 | 60 NUT (M10X1.5-THD) | 13 | |
| 8T4136 | 61 BOLT (M10X1.5X25-MM) | 14 | |
| 8T4137 | 62 BOLT (M10X1.5X20-MM) | 59 | |
| 8T4139 | 63 BOLT (M12X1.75X30-MM) | 10 | |
| 8T4184 | 64 BOLT (M12X1.75X45-MM) | 2 | |
| 8T4186 | 65 BOLT (M10X1.5X40-MM) | 3 | |
| 8T4195 | 66 BOLT (M10X1.5X30-MM) | 9 | |
| 8T4223 | 68 WASHER-HARD (13.5X25.5X3-MM THK) | 18 | |
| 8T4244 | 69 NUT (M12X1.75-THD) | 1 | |
| 8T4956 | 70 BOLT (M12X1.75X35-MM) | 4 | |
| 2808912 | 71 BOLT (M10X1.5X75-MM) | 1 | |
| 8T6466 | 72 BOLT (M10X1.5X60-MM) | 2 | |
| 8T6776 | 73 ADAPTER | 2 | |
| 2A2677 | 74 SPACER (10.7X17.14X19.05-MM THK) | 2 | |
| 9X8250 | 75 CLIP (LOOP) | 11 | |
| 2310336 | 76 STUD-TAPERLOCK (M10X1.5X70-MM) | 4 | |
| 3W9670 | 77 BOSS | 4 | |
| 3445675 | 78 NUT (M10X1.5-THD) | 1 | |
| 3293356 | 79 NUT (M12X1.75-THD) | 1 | |
| 1976453 | 80 BRACKET AS | 1 | |
| 6V1874 | 81 GROMMET (31-MM ID) | 1 | |
| 6K8178 | 82 CLIP (LOOP) | 1 | |
| 5P7469 | 83 CLIP (TAB) | 1 | |
| 5P7468 | 84 CLIP (SLOT) | 1 |
