System And Components
483-3114 LINES GP-PUMPS/N 2T41-UP
Group No: 483-3114 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6U0455 | 1 STRAP | 2 | |
| 6U0456 | 2 STRAP | 5 | |
| 1483373 | 3 HOSE AS | 1 | |
| 1488335 | 4 CONNECTOR AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V8635 | CONNECTOR | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1504046 | 5 ADAPTER AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 5P1404 | ADAPTER | 1 | |
| 1837264 | 6 VALVE AS-FLUID SAMPLING (HYDRAULIC OIL) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1858833 | 7 ELBOW AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 1292327 | ELBOW | 1 | |
| 2681621 | 8 FITTING AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1241212 | FITTING | 1 | |
| 2905562 | 9 MOUNT (DUAL SWIVEL) | 2 | |
| 3069589 | 10 HOSE AS | 1 | |
| 3605604 | 11 VALVE AS-CONTROL (HYDRAULIC OIL TEMP) | 1 | |
| 2385085 | SEAL-O-RING | 1 | |
| 3691487 | 12 SWITCH AS-PRESSURE (POWER TRAIN OIL) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 3845850 | 13 MANIFOLD | 1 | |
| 3879283 | 14 HOSE AS | 1 | |
| 3879425 | 15 HOSE AS | 1 | |
| 3935451 | 16 HOSE AS | 1 | |
| 4223863 | 17 FILTER GP-OIL (POWER TRAIN)(POWER TRAIN) | 1 | |
| 4447464 | 18 HOSE AS | 1 | |
| 4470957 | 19 TUBE AS | 1 | |
| 4470958 | 20 TUBE AS | 1 | |
| 4480762 | 21 HOSE AS | 1 | |
| 4833928 | 22 BRACKET AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 2 | |
| 1060421 | BOSS-THREADED (M12X1.75-THD) | 1 | |
| 4941928 | 23 FITTING GP-HYDRAULIC | 1 | |
| 1488313 | 24 ADAPTER AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 5P6944 | ADAPTER | 1 | |
| 1488316 | 25 CONNECTOR AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8647 | CONNECTOR | 1 | |
| 1488327 | 26 CONNECTOR AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488347 | 27 ELBOW AS | 4 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9007 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1503033 | 28 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 8T0164 | ELBOW | 1 | |
| 1557321 | 29 ADAPTER AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V1722 | ADAPTER | 1 | |
| 1932120 | 30 GROMMET | 2 | |
| 1P4578 | 31 FLANGE-HALF | 2 | |
| 2287092 | 32 SEAL-O-RING | 2 | |
| 3J1907 | 33 SEAL-O-RING | 2 | |
| 3U2754 | 34 CLIP (LOOP) | 2 | |
| 3U2755 | 35 CLIP (LOOP) | 3 | |
| 4J0520 | 36 SEAL-O-RING | 2 | |
| 4J0522 | 37 SEAL-O-RING | 2 | |
| 5K3294 | 38 CLIP | 1 | |
| 5P7470 | 39 CLIP (SLOT) | 4 | |
| 5P7471 | 40 CLIP (TAB) | 4 | |
| 5P8182 | 41 GROMMET (46-MM ID) | 4 | |
| 6P0699 | 42 GROMMET | 2 | |
| 6V0852 | 43 CAP-DUST | 1 | |
| 6V1867 | 44 CLIP (SLOT) | 2 | |
| 6V1868 | 45 CLIP (TAB) | 2 | |
| 7X7729 | 46 WASHER (11X25X3-MM THK) | 4 | |
| 8C3206 | 47 FLANGE-HALF | 4 | |
| 8T4121 | 48 WASHER-HARD (11X21X2.5-MM THK) | 21 | |
| 8T4136 | 49 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4137 | 50 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4183 | 51 BOLT (M12X1.75X40-MM) | 4 | |
| 8T4185 | 52 BOLT (M10X1.5X50-MM) | 2 | |
| 8T4189 | 53 BOLT (M8X1.25X20-MM) | 4 | |
| 8T4192 | 54 BOLT (M12X1.75X25-MM) | 1 | |
| 8T4195 | 55 BOLT (M10X1.5X30-MM) | 4 | |
| 8T4196 | 56 BOLT (M10X1.5X35-MM) | 8 | |
| 8T4223 | 57 WASHER-HARD (13.5X25.5X3-MM THK) | 7 | |
| 8T4224 | 58 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T4244 | 59 NUT (M12X1.75-THD) | 2 | |
| 8T6466 | 60 BOLT (M10X1.5X60-MM) | 2 | |
| 9D6196 | 61 CLIP (SLOT) | 1 | |
| 9D6197 | 62 CLIP (TAB) | 1 | |
| 1189573 | 63 BOLT-12 POINT HEAD (M10X1.5X35-MM) | 4 |
