System And Components
433-6975 WIRING GP-ELECTRONIC CONTROLS/N 2L61-UP
Group No: 433-6975 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2462641 | 1 PADLOCK GP | 1 | |
| 5P8500 | KEY | 1 | |
| 8S2634 | 3 COVER AS | 1 | |
| 9G2758 | 4 LOCKOUT-SWITCH | 1 | |
| 4873407 | 5 CLIP | 1 | |
| 3379078 | 6 SWITCH GP-MAGNETIC (24-VOLT TO 32-VOLT) | 1 | |
| 3429671 | 7 RECEPTACLE AS-AUXILIARY START | 1 | |
| 3570111 | 8 PLATE | 2 | |
| 3671782 | 9 CABLE AS | 1 | |
| 1939141 | COVER-TERMINAL | 1 | |
| 8N0869 | COVER-TERMINAL (RED) | 1 | |
| 2352677 | TERMINAL-RING | 1 | |
| 2352678 | TERMINAL-RING | 1 | |
| 1598049 | CABLE (00-GA, RED)(124-CM) | ||
| 3671783 | 10 CABLE AS | 1 | |
| 1598050 | CABLE (00-GA, BLACK)(23-CM) | ||
| 0375197 | BOOT | 2 | |
| 2352678 | TERMINAL-RING | 2 | |
| 3671787 | 11 CABLE AS | 1 | |
| 1M4986 | TERMINAL-RING (0-GA, 1/2-IN SCREW) | 1 | |
| 5P0760 | CABLE (0-GA, RED)(34-CM) | ||
| 6V2722 | TUBE-HEAT SHRINK (25.4-MM DIA)(0.1-M) | ||
| 8N0869 | COVER-TERMINAL (RED) | 1 | |
| 0301709 | TERMINAL-RING (0-GA, 1/4-IN SCREW) | 1 | |
| 4533481 | 12 CABLE AS | 1 | |
| 1598049 | CABLE (00-GA, RED)(76-CM) | ||
| 6V2722 | TUBE-HEAT SHRINK (25.4-MM DIA)(0.1-M) | ||
| 3088161 | COVER-TERMINAL | 1 | |
| 2352677 | TERMINAL-RING | 1 | |
| 2352678 | TERMINAL-RING | 1 | |
| 3849808 | 13 PLATE AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 2 | |
| 3923507 | 14 CABLE AS | 1 | |
| 1598050 | CABLE (00-GA, BLACK)(112-CM) | ||
| 2352678 | TERMINAL-RING | 2 | |
| 4337625 | 15 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 4337627 | 16 CABLE AS | 1 | |
| 1598049 | CABLE (00-GA, RED)(61-CM) | ||
| 1903848 | TERMINAL-RING (00-GA, 1/2-IN SCREW) | 1 | |
| 2352677 | TERMINAL-RING | 1 | |
| 3088161 | COVER-TERMINAL | 1 | |
| 4459941 | 17 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 4475919 | 18 CABLE AS | 1 | |
| 1598050 | CABLE (00-GA, BLACK)(97-CM) | ||
| 2352678 | TERMINAL-RING | 2 | |
| 1245814 | 19 BLOCK GP-JUNCTION (BATTERY) | 1 | |
| 2636342 | 20 CLIP | 16 | |
| 2G8767 | 21 WASHER (10.5X60X3-MM THK) | 2 | |
| 5C9553 | 22 BOLT (M6X1X16-MM) | 4 | |
| 5G6505 | 23 WASHER (25X38X14-MM THK) | 3 | |
| 6G2256 | 24 CLAMP | 2 | |
| 7N0718 | 25 SWITCH GP-DISCONNECT | 1 | |
| 7X7729 | 26 WASHER (11X25X3-MM THK) | 4 | |
| 8T4121 | 27 WASHER-HARD (11X21X2.5-MM THK) | 20 | |
| 8T4136 | 28 BOLT (M10X1.5X25-MM) | 7 | |
| 8T4137 | 29 BOLT (M10X1.5X20-MM) | 14 | |
| 8T4139 | 30 BOLT (M12X1.75X30-MM) | 2 | |
| 8T4196 | 31 BOLT (M10X1.5X35-MM) | 1 | |
| 8T4200 | 32 BOLT (M8X1.25X16-MM) | 1 | |
| 8T4223 | 33 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4224 | 34 WASHER-HARD (8.8X16X2-MM THK) | 6 | |
| 8T4908 | 35 BOLT (M8X1.25X25-MM) | 5 | |
| 9X8256 | 36 WASHER (6.6X12X2-MM THK) | 4 | |
| 8T4195 | 37 BOLT (M10X1.5X30-MM) | 2 | |
| 4500998 | 38 SPACER (13.5X25X12-MM THK) | 1 | |
| 4803540 | 39 PLATE | 1 |
