System And Components
540-2283 WIRING GP-ENGINEAN ATTACHMENT
Group No: 540-2283
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9Y2700 | 1 SPACER (11X20X42-MM THK) | 1 | |
| 5N2126 | 2 CONNECTOR (THERMOCOUPLE) | 16 | |
| 9X6772 | 3 STRAP-CABLE | 58 | |
| 1546626 | 4 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1834274 | 5 BRACKET | 1 | |
| 2341644 | 6 CONTROL GP-ENGINE MONITORING (THERMOCOUPLE) | 1 | |
| 2391844 | 7 SPACER (14X25X70-MM) | 1 | |
| 2450522 | 8 BRACKET | 1 | |
| 2450523 | 9 BRACKET | 3 | |
| 2566453 | 10 SENSOR-TEMPERATURE (2-PIN)(ENGINE COOLANT TEMPERATURE) | 1 | |
| 2566453 | 10A SENSOR-TEMPERATURE (2-PIN)(AIR INLET MANIFOLD, PRIMARY) | 1 | |
| 2566453 | 10B SENSOR-TEMPERATURE (2-PIN)(AIR INLET MANIFOLD, SECONDARY) | 1 | |
| 2566453 | 10C SENSOR-TEMPERATURE (2-PIN)(ENGINE OIL BLOCK INLET) | 1 | |
| 2566453 | 10D SENSOR-TEMPERATURE (2-PIN)(TURBINE INLET) | 1 | |
| 2613856 | 11 BRACKET AS | 1 | |
| 8C3334 | RIVET-TUBULAR | 2 | |
| 5221641 | 12 SENSOR GP-SPEED (CAMSHAFT POSITION) | 1 | |
| 5221641 | 12A SENSOR GP-SPEED (CRANKSHAFT POSITION) | 1 | |
| 2786469 | 13 GROMMET | 6 | |
| 2818666 | 14 THERMOWELL | 2 | |
| 3591828 | 15 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 3832990 | 16 SENSOR GP-TEMPERATURE (THERMOCOUPLE)(CYLINDER EXHAUST) | 16 | |
| 4189798 | 17 BRACKET | 1 | |
| 4849878 | 18 SENSOR GP-PRESSURE (COMPRESSOR INLET AIR, RH) | 1 | |
| 4849878 | 18A SENSOR GP-PRESSURE (COMPRESSOR INLET AIR, LH) | 1 | |
| 4849879 | 19 SENSOR GP-PRESSURE (TURBOCHARGER INLET, LH) | 1 | |
| 4849879 | 19A SENSOR GP-PRESSURE (TURBOCHARGER INLET, RH) | 1 | |
| 5256733 | 20 HARNESS AS-ENGINE (PYROMETER) | 1 | |
| 5358805 | 21 BRACKET AS | 1 | |
| 9F6445 | NUT-WELD (1/4-20-THD) | 4 | |
| 5407383 | 22 WIRING GP-ENGINE | 1 | |
| 0L1143 | 23 BOLT (3/8-16X2.5-IN) | 2 | |
| 0L1352 | 24 BOLT (3/8-16X3.25-IN) | 1 | |
| 0L2070 | 25 BOLT (3/8-16X2.25-IN) | 1 | |
| 0S0509 | 26 BOLT (3/8-16X0.75-IN) | 9 | |
| 1653931 | 27 BOLT (3/8-16X1.75-IN) | 1 | |
| 0S1588 | 28 BOLT (3/8-16X1.25-IN) | 12 | |
| 1653929 | 29 BOLT (3/8-16X1.5-IN) | 1 | |
| 0S1594 | 30 BOLT (3/8-16X1-IN) | 19 | |
| 0S1615 | 31 BOLT (1/4-20X0.75-IN) | 4 | |
| 0S1620 | 32 BOLT (1/2-13X0.75-IN) | 2 | |
| 0S1621 | 33 BOLT (1/2-13X1-IN) | 1 | |
| 0S1619 | 34 BOLT (3/8-16X3-IN) | 1 | |
| 1153073 | 35 CLIP AS-CONNECTING | 1 | |
| 1189901 | 36 SPACER (12X20X10-MM THK) | 3 | |
| 1275447 | 37 SPACER (10.5X20X12-MM THK) | 2 | |
| 1325789 | 38 CLIP (LADDER) | 4 | |
| 1391398 | 39 CLIP (LOOP) | 4 | |
| 1497738 | 40 CLIP (LOOP) | 1 | |
| 1623858 | 41 SPACER (12X19X33.5-MM THK) | 1 | |
| 1751367 | 42 SPACER (8.8X16X10-MM THK) | 1 | |
| 1772215 | 43 STRAP-DUAL CLAMP | 1 | |
| 1B2886 | 44 BOLT (1/2-13X3.75-IN) | 1 | |
| 1B7182 | 45 BOLT (5/16-18X1.25-IN) | 1 | |
| 2123426 | 46 SENSOR GP-SPEED (MAGNETIC, LH) | 1 | |
| 2123426 | 46A SENSOR GP-SPEED (MAGNETIC, RH) | 1 | |
| 2147566 | 47 SEAL-O-RING | 3 | |
| 2159632 | 48 SPACER (12X20X20-MM THK) | 1 | |
| 2287100 | 49 SEAL-O-RING | 1 | |
| 2385080 | 50 SEAL-O-RING | 3 | |
| 2771873 | 51 CLIP (LADDER) | 1 | |
| 2B2694 | 52 BOLT (5/16-18X2-IN) | 1 | |
| 2M3403 | 53 BOLT (3/8-16X3.63-IN) | 4 | |
| 3118802 | 54 SPACER (10.5X19X57-MM THK) | 5 | |
| 3513525 | 55 CLIP (LADDER) | 1 | |
| 3523964 | 56 CLIP (LADDER) | 1 | |
| 3523965 | 57 CLIP (LADDER) | 2 | |
| 3523966 | 58 CLIP (LADDER) | 4 | |
| 3523967 | 59 CLIP (LADDER) | 2 | |
| 3523968 | 60 CLIP (LADDER) | 3 | |
| 3523969 | 61 CLIP (LADDER) | 4 | |
| 3523970 | 62 CLIP (LADDER) | 1 | |
| 3B1915 | 63 BOLT (3/8-16X1.375-IN) | 2 | |
| 3E4352 | 64 WASHER-HARD (8.8X20.5X2.5-MM THK) | 1 | |
| 3K0360 | 65 SEAL-O-RING | 1 | |
| 4L6454 | 66 BOLT (3/8-16X1-IN) | 1 | |
| 4P7429 | 67 CLIP (LADDER) | 1 | |
| 4P7581 | 68 CLIP (LADDER) | 4 | |
| 4P8134 | 69 CLIP (LADDER) | 19 | |
| 5402276 | 70 WIRING GP-ENGINE (RAIL, RH) | 1 | |
| 5402280 | 71 WIRING GP-ENGINE (RAIL, LH) | 1 | |
| 5M2894 | 72 WASHER-HARD (10.2X18.5X2.5-MM THK) | 42 | |
| 5P0537 | 73 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 5P8245 | 74 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 5V9221 | 75 SPACER (13.8X25X25-MM THK) | 2 | |
| 6V1581 | 76 CLIP (SLOT) | 4 | |
| 6V1582 | 77 CLIP (TAB) | 4 | |
| 6V1612 | 78 BOLT (1/2-13X9.75-IN) | 2 | |
| 6V6609 | 79 SEAL-O-RING | 5 | |
| 7D1649 | 80 WASHER-HARD (13.5X32X5-MM THK) | 2 | |
| 7G5984 | 81 CLIP (TAB) | 6 | |
| 7G5985 | 82 CLIP (SLOT) | 6 | |
| 8T4223 | 83 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4835 | 84 BOLT (1/2-13X2-IN) | 2 | |
| 8T4896 | 85 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 9S4185 | 86 PLUG (3/4-16-THD) | 2 | |
| 9S8752 | 87 NUT-FULL (3/8-16-THD) | 4 | |
| 9X6458 | 88 WASHER-HARD (10.2X22.5X3-MM THK) | 16 |
