System And Components
503-4827 STARTING MOTOR GP-ELECTRICS/N E2N1-157; E2T1-194
Group No: 503-4827
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 4 | |
| 1339637 | 2 BRACKET | 1 | |
| 2780518 | 3 SPACER (10.5X20X62.3-MM THK) | 1 | |
| 3496606 | 4 STARTING MOTOR GP-ELECTRIC (24-VOLT) | 2 | |
| 3694098 | 5 SWITCH AS-DISCONNECT (MASTER) | 1 | |
| 2H3922 | LOCKWASHER | 1 | |
| 6F7045 | NUT-FULL (3/8-24-THD) | 2 | |
| 8H5303 | NUT (3/4-16-THD) | 2 | |
| 4498192 | KIT-KNOB (DISCONNECT SWITCH) | 1 | |
| 4674209 | 6 HARNESS AS-SENSOR | 1 | |
| 4707164 | 7 CABLE AS | 1 | |
| 1598053 | CABLE-ELECTRICAL (0000-GA, RED)(24-CM) | ||
| 2942319 | COVER-TERMINAL (BLACK) | 1 | |
| 3482317 | TERMINAL AS-RING | 1 | |
| 3L7634 | TERMINAL-RING (0000-GA, 1/2-IN SCREW) | 1 | |
| 1355010 | TUBE-HEAT SHRINK (52-MM DIA)(5-CM) | ||
| 5003009 | 8 BRACKET | 1 | |
| 5034828 | 9 CABLE AS | 1 | |
| 0319295 | TERMINAL-RING (0000-GA, 3/8-IN SCREW) | 1 | |
| 1598054 | CABLE-ELECTRICAL (0000-GA, BLACK)(84-CM) | ||
| 2942319 | COVER-TERMINAL (BLACK) | 1 | |
| 3482317 | TERMINAL AS-RING | 2 | |
| 3L7634 | TERMINAL-RING (0000-GA, 1/2-IN SCREW) | 1 | |
| 1355010 | TUBE-HEAT SHRINK (52-MM DIA)(5-CM) | ||
| 5039238 | 10 CABLE AS | 1 | |
| 9X4519 | BOOT (RED) | 1 | |
| 1598053 | CABLE-ELECTRICAL (0000-GA, RED)(39-CM) | ||
| 3482317 | TERMINAL AS-RING | 1 | |
| 3L7634 | TERMINAL-RING (0000-GA, 1/2-IN SCREW) | 1 | |
| 1355010 | TUBE-HEAT SHRINK (52-MM DIA)(5-CM) | ||
| 0L1143 | 11 BOLT (3/8-16X2.5-IN) | 1 | |
| 0L1352 | 12 BOLT (3/8-16X3.25-IN) | 1 | |
| 0S1594 | 14 BOLT (3/8-16X1-IN) | 1 | |
| 1566175 | 15 CLIP (LADDER) | 3 | |
| 2A4639 | 16 BOLT (3/8-16X1.625-IN) | 1 | |
| 5M2894 | 17 WASHER-HARD (10.2X18.5X2.5-MM THK) | 5 | |
| 7J8902 | 18 BOLT-12 POINT HEAD (5/8-11X1.5-IN) | 6 | |
| 7X2619 | 19 BOLT (M6X1X10-MM) | 3 | |
| 8M2773 | 20 CLIP (LOOP) | 3 | |
| 9S8752 | 21 NUT-FULL (3/8-16-THD) | 1 | |
| 9W1991 | 22 SPACER (10.7X17.1X40-MM THK) | 1 | |
| 9X8267 | 23 WASHER (6.6X12X2-MM THK) | 3 |
