System And Components
475-6395 LINES GP-AIR COMPRESSORS/N NTE1-UP
Group No: 475-6395
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3R2705 | 1 UNION-FLARED | 1 | |
| 4W1117 | 2 ADAPTER | 1 | |
| 9G4918 | 3 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 7N1577 | BRACKET | 1 | |
| 1182763 | 4 TUBE AS | 1 | |
| 1358289 | 5 HOSE AS | 1 | |
| 1765647 | 6 PLATE | 1 | |
| 1919383 | 7 TUBE AS | 1 | |
| 4676297 | 8 BRACKET AS | 1 | |
| 4744719 | 9 TUBE AS | 1 | |
| 4758127 | 10 TUBE AS | 1 | |
| 0047626 | 11 CONNECTOR (FLARED) | 1 | |
| 0307949 | 12 ELBOW | 1 | |
| 0307950 | 13 ELBOW | 1 | |
| 0308195 | 14 CONNECTOR | 1 | |
| 0S0509 | 15 BOLT (3/8-16X0.75-IN) | 1 | |
| 1653929 | 16 BOLT (3/8-16X1.5-IN) | 3 | |
| 0S1617 | 17 BOLT (5/16-18X0.75-IN) | 2 | |
| 8M9124 | 18 WASHER (10X22.5X8-MM THK) | 1 | |
| 1B8471 | 19 CLIP | 1 | |
| 1P7625 | 20 ELBOW | 1 | |
| 2385080 | 21 SEAL-O-RING | 1 | |
| 2385081 | 22 SEAL-O-RING | 2 | |
| 2385082 | 23 SEAL-O-RING | 1 | |
| 2A4639 | 24 BOLT (3/8-16X1.625-IN) | 1 | |
| 2N1287 | 25 ELBOW-FLARED | 1 | |
| 2N1288 | 26 ELBOW | 1 | |
| 3537953 | 27 GROMMET | 1 | |
| 3B1915 | 28 BOLT (3/8-16X1.375-IN) | 1 | |
| 3R5387 | 29 CONNECTOR | 1 | |
| 7C0307 | 30 GASKET | 1 | |
| 8M2772 | 31 CLIP (LOOP) | 1 | |
| 8M7065 | 32 GASKET (AIR INLET) | 1 | |
| 8T1889 | 33 CLIP (SLOT) | 1 | |
| 8T1890 | 34 CLIP (TAB) | 1 | |
| 9X6458 | 35 WASHER-HARD (10.2X22.5X3-MM THK) | 6 |
