System And Components
3T-1513 VALVE GP-PRESSURE CONTROLS/N 4FY1-UP
Group No: 3T-1513
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4948052 | 1 BODY AS | 1 | |
| 5S7906 | STOP | 4 | |
| 6F4863 | PIN-GROOVED | 4 | |
| 8P7385 | BODY-VALVE | 1 | |
| 5M2504 | 4 SLUG | 7 | |
| 9P0683 | 5 SPRING | 7 | |
| 9P0656 | 6 SPOOL AS | 7 | |
| 4B9880 | 6A BALL | 1 | |
| 1S1636 | 6B RETAINER | 1 | |
| 1S1638 | 6C RING-RETAINING | 1 | |
| 4M2381 | 6D SPRING | 1 | |
| 8E4592 | 7 STOP | 7 | |
| 9W7410 | 8 SPRING | 3 | |
| 7T0569 | 9 SPRING | 6 | |
| 1607578 | 10 BODY-LOAD PISTON | 7 | |
| 4M1751 | 11 SPACER (15.09X0.4-MM THK) | 14 | |
| 5J2721 | 12 SHIM (0.13-MM THK) | 14 | |
| 6J3993 | 13 SHIM (0.25-MM THK) | 14 | |
| 5J1036 | 14 SHIM (0.8-MM THK) | 35 | |
| 7G7431 | 15 PISTON-SELECTOR | 7 | |
| 9P0687 | 16 PISTON-LOAD | 7 | |
| 3218641 | 18 PLUG AS | 14 | |
| 9S8001 | PLUG (5/16-24-THD) | 1 | |
| 2385078 | SEAL-O-RING | 1 | |
| 3218643 | 19 PLUG AS | 6 | |
| 9G7132 | PLUG-ORIFICE | 1 | |
| 2385078 | SEAL-O-RING | 1 | |
| 3706344 | 20 ORIFICE AS | 1 | |
| 3706345 | 21 ORIFICE AS | 4 | |
| 3706346 | 22 ORIFICE AS | 2 | |
| 9W7412 | 23 SPRING | 3 | |
| 9D7884 | 24 SPRING | 7 | |
| 9W7411 | 25 SPRING | 1 | |
| 7S4594 | 26 PISTON-LOAD | 1 | |
| 2016618 | 27 PLUG AS-ORIFICE | 1 | |
| 5P7812 | SEAL-O-RING | 1 | |
| 7T0571 | 28 SPRING | 1 | |
| 8L2777 | 29 SEAL-O-RING | 7 | |
| 3133492 | 31 PLUG AS | 2 | |
| 9S4190 | PLUG-O-RING (7/8-14-THD) | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 5P9287 | 32 WASHER-HARD (7.2X32X2-MM THK) | 1 | |
| 0310214 | 33 BOLT-LOCKING (1/4-20X0.5-IN) | 1 | |
| 5P0537 | 36 WASHER-HARD (7.2X14.5X2-MM THK) | 14 | |
| 5L9018 | 37 BOLT-SOCKET HEAD (1/4-20X1.75-IN) | 14 |
