228-3238 MOTOR GP-PISTON -TRAVELS/N EBF1-UP

Group No: 228-3238 · Commonality

Part Number	Part Name	Qty
1T0936	1 PLUG-ORIFICE	2
4B4158	2 SCREW-DRIVE (NO 4X0.25-IN)	4
6V3382	3 SEAL-LIP TYPE	1
8J2559	4 PLATE-WARNING (OIL FILL)	1
0874786	5 ADAPTER	1
1185805	6 BEARING-SPECIAL RACE	1
1241530	7 BARREL AS	1
1241536	8 DISC-FRICTION	5
1241537	9 PLATE-SEPARATOR	6
1241541	10 PIN	2
1241554	11 SPRING	1
1241557	12 RETAINER	2
1241561	13 SPRING-BRAKE	20
1264002	14 SEAL-O-RING	2
1264003	15 SEAL-O-RING	1
1264004	16 RING-BACKUP	1
1264040	17 RING-BACKUP	1
3571728	18 SPACER (70.4X80X2.3-MM THK)	1
1375646	19 SPACER (70.4X87.5X7.6-MM THK)	1
1437140	20 KEY	2
1483548	21 BEARING-SPECIAL RACE	1
1491207	22 PLATE	1
1554897	23 PISTON AS	9
1597320	24 PLATE-RETAINER	1
1673872	25 SPOOL	1
1757887	26 DOWEL	2
3435942	27 HEAD AS-PUMP	1
0965916	SEAT	2
1241555	PLUG	8
1932301	28 SHAFT	1
1954456	29 PLUG-ORIFICE	1
3434855	30 PISTON-ACTUATOR	1
2266544	31 PISTON-BRAKE	1
2287074	32 PLATE-CAM	1
2305483	33 SPRING	1
2316550	34 HOLD-DOWN	1
2323868	35 WASHER-BELLEVILLE	4
2925991	36 BODY AS	1
1241555	PLUG	4
0951572	37 SEAL-O-RING	2
0965919	38 RING-BACKUP	2
1437319	39 RACE-ROLLER BEARING	1
2D6642	40 BALL	2
2M9780	41 SEAL-O-RING	1
2R1236	42 RING-RETAINING (LOCK, INTERNAL)	1
3D2824	43 SEAL-O-RING	2
3K0360	44 SEAL-O-RING	2
5B9318	45 BALL	1
5P7684	46 PLUG	1
6K6307	47 SEAL-O-RING	1
7Y5219	48 SEAL-O-RING	2
8T4187	49 BOLT (M20X2.5X80-MM)	6
9S4183	50 PLUG (1-1/16-12-THD)	2
9S4185	51 PLUG (3/4-16-THD)	2
2266473	KIT-SEAL (TRAVEL MOTOR)	1
