System And Components
529-8565 LINES GP-WATER -SCACS/N GF51-UP
Group No: 529-8565
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1N3872 | 1 SUPPORT | 1 | |
| 2W5225 | 2 FLANGE | 3 | |
| 3P6061 | 3 GASKET | 1 | |
| 4W0530 | 4 RING-RETAINING | 4 | |
| 4W0531 | 5 RETAINER | 8 | |
| 9Y8283 | 6 ELBOW | 1 | |
| 2086270 | 7 CLAMP | 8 | |
| 2140731 | 8 BRACKET | 1 | |
| 2617951 | 9 JOINT AS-TUBE | 2 | |
| 2617952 | SEAL | 2 | |
| 3352477 | 10 ELBOW | 1 | |
| 3526503 | 11 PLUG AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 3526502 | PLUG | 1 | |
| 3578797 | 12 BRACKET | 1 | |
| 3586242 | 13 TUBE | 1 | |
| 3586243 | 14 TUBE | 1 | |
| 3586246 | 15 BRACKET | 1 | |
| 3621347 | 16 ADAPTER | 1 | |
| 5458389 | 17 HOSE AS-WATER | 1 | |
| 5298566 | 18 TUBE | 1 | |
| 5384264 | 19 ELBOW | 1 | |
| 0L1143 | 20 BOLT (3/8-16X2.5-IN) | 1 | |
| 0L1329 | 21 BOLT (1/2-13X3-IN) | 2 | |
| 0L1351 | 22 BOLT (3/8-16X0.875-IN) | 2 | |
| 1653931 | 23 BOLT (3/8-16X1.75-IN) | 6 | |
| 0S1588 | 24 BOLT (3/8-16X1.25-IN) | 2 | |
| 1653929 | 25 BOLT (3/8-16X1.5-IN) | 2 | |
| 0S1594 | 26 BOLT (3/8-16X1-IN) | 10 | |
| 0S1608 | 27 BOLT (3/8-16X3.75-IN) | 2 | |
| 0T0055 | 28 BOLT (3/8-16X4.25-IN) | 2 | |
| 0T0573 | 29 BOLT (3/8-16X2.75-IN) | 2 | |
| 1448344 | 30 SPACER (11X19X20-MM THK) | 1 | |
| 5004236 | 31 TEE AS | 1 | |
| 6D7128 | SEAL-O-RING | 2 | |
| 6V3250 | SEAL-O-RING | 1 | |
| 6V8781 | TEE | 1 | |
| 1A2029 | 32 BOLT (3/8-16X1.125-IN) | 2 | |
| 1F7958 | 33 NUT-FULL (1/2-13-THD) | 12 | |
| 3586245 | 34 TUBE AS | 1 | |
| 3B1915 | 35 BOLT (3/8-16X1.375-IN) | 8 | |
| 3E4305 | 36 BOLT (5/8-18X1.75-IN) | 4 | |
| 3960414 | 37 ELBOW AS | 1 | |
| 6D7128 | SEAL-O-RING | 1 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 6V9876 | ELBOW | 1 | |
| 3J5390 | 38 PLUG (3/8-18-THD) | 3 | |
| 5803084 | 39 ELBOW | 1 | |
| 5G1442 | 40 GASKET | 2 | |
| 5M2894 | 41 WASHER-HARD (10.2X18.5X2.5-MM THK) | 32 | |
| 5N1939 | 42 COVER | 1 | |
| 5N1940 | 43 GASKET | 1 | |
| 5P8245 | 44 WASHER-HARD (13.5X25.5X3-MM THK) | 14 | |
| 6V1581 | 45 CLIP (SLOT) | 4 | |
| 6V1582 | 46 CLIP (TAB) | 4 | |
| 6V5064 | 47 SEAL-O-RING | 1 | |
| 6V9829 | 48 CAP (ORFS) | 1 | |
| 8M9024 | 49 WASHER-HARD (10.2X22.5X5-MM THK) | 2 | |
| 8S9191 | 50 BOLT (3/8-16X4-IN) | 2 | |
| 8T1919 | 51 SEAL-O-RING | 4 | |
| 8T6765 | 52 PLUG-PIPE (1/4-18-THD) | 2 | |
| 9C5344 | 53 SPACER (10.5X20X18-MM THK) | 4 | |
| 9L9132 | 54 WASHER-HARD (10.2X25.5X2.5-MM THK) | 2 | |
| 9S4181 | 55 PLUG (1-5/16-12-THD) | 1 | |
| 9S8752 | 56 NUT-FULL (3/8-16-THD) | 11 | |
| 9X6458 | 57 WASHER-HARD (10.2X22.5X3-MM THK) | 8 | |
| 9X7458 | 58 SEAL-O-RING | 1 | |
| 2B0947 | 59 BOLT (1/2-13X2.25-IN) | 12 | |
| 9Y6893 | 60 GASKET | 3 | |
| 9Y8069 | 61 GASKET | 1 |
