System And Components
415-3785 MOUNTING GP-ALTERNATOR & COMPRS/N H4R1-UP
Group No: 415-3785
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1323071 | 1 SEAL | 1 | |
| 3298797 | 2 BELT TENSIONER | 1 | |
| 3331207 | 3 IDLER AS | 1 | |
| 3672824 | 4 PULLEY AS | 1 | |
| 3672817 | PULLEY (8-GROOVE) | 1 | |
| 4652689 | SEAL-WEAR SLEEVE | 1 | |
| 4162564 | 5 BRACKET AS | 1 | |
| 2178973 | 5A BUSHING | 2 | |
| 1456115 | DOWEL | 2 | |
| 0S1585 | 6 BOLT (1/2-13X1.5-IN) | 4 | |
| 0S1590 | 7 BOLT (3/8-16X2-IN) | 4 | |
| 1A1460 | 8 BOLT (1/2-13X2-IN) | 2 | |
| 5P8245 | 9 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 6V5839 | 10 WASHER (11X21X2.5-MM THK) | 1 | |
| 8T0643 | 11 BOLT (M10X1.5X80-MM) | 1 | |
| 1079570 | 12 SEAL-O-RING | 1 |
