System And Components
439-2110 LINES GP-FUELS/N LTZ1-162
Group No: 439-2110
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V0852 | 1 CAP-DUST | 1 | |
| 7K1181 | 2 STRAP-CABLE | 1 | |
| 8T9655 | 3 MOUNT-ISOLATION | 6 | |
| 1336934 | 4 SPACER (11X20X25-MM THK) | 1 | |
| 1488373 | 5 ELBOW AS | 1 | |
| 6V8400 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 8C3364 | ELBOW | 1 | |
| 1495264 | 6 VALVE AS | 1 | |
| 1716723 | 7 ELBOW AS | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 8T8899 | ELBOW | 1 | |
| 1782345 | 8 SENSOR GP-LIQUID LEVEL (WATER IN FUEL) | 1 | |
| 1911782 | 9 SPACER (8.5X12.7X38.2-MM THK) | 1 | |
| 1911783 | 10 SPACER (8.5X12.7X87.3-MM THK) | 2 | |
| 2048000 | 11 MOUNTING-CABLE TIE | 2 | |
| 2153665 | 12 ELBOW | 1 | |
| 2790143 | 13 VALVE | 1 | |
| 2815934 | 14 ELBOW AS | 2 | |
| 6V9877 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3038195 | 15 PLATE AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 3038196 | PLATE | 1 | |
| 3095137 | 16 CONNECTOR AS | 1 | |
| 6V8635 | CONNECTOR | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3108716 | 17 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 3 | |
| 3196248 | 18 UNION AS | 1 | |
| 5P9560 | UNION | 1 | |
| 2385082 | SEAL-O-RING | 2 | |
| 3211326 | 19 BASE AS-FILTER | 3 | |
| 3232268 | STUD-HOLLOW | 1 | |
| 3227970 | 20 BRACKET AS | 1 | |
| 5P2251 | GUSSET | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 3378235 | 21 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 3380085 | 22 BRACKET | 1 | |
| 3501571 | 23 BRACKET AS | 1 | |
| 3574574 | 24 ADAPTER AS | 1 | |
| 8D8428 | ADAPTER | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3580360 | 25 CORE AS-OIL COOLER | 1 | |
| 3614742 | ISOLATOR | 4 | |
| 3696670 | 26 VALVE-CHECK | 1 | |
| 3717210 | 27 CONNECTOR | 1 | |
| 4164703 | 28 PUMP GP-FUEL PRIMING (ELECTRIC) | 1 | |
| 4385386 | 29 FILTER AS-WATER SEP & FUEL (ULTRA HIGH EFFICIENCY) | 3 | |
| 4790856 | FILTER AS-WATER SEP & FUEL | 1 | |
| 4597737 | 30 BLOCK | 1 | |
| 4635421 | 31 PUMP GP-FUEL | 1 | |
| 4701666 | 32 HOSE AS | 1 | |
| 4701667 | 33 HOSE AS | 1 | |
| 4752685 | 34 HOSE AS | 1 | |
| 4752691 | 35 HOSE AS | 2 | |
| 4752692 | 36 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 3 | |
| 4792171 | 37 BOLT AS | 30 | |
| 4792172 | 38 BOLT AS | 2 | |
| 5032810 | 39 HOSE AS | 1 | |
| 5051266 | 40 BRACKET AS | 1 | |
| 5086015 | 41 HOSE AS | 1 | |
| 0673045 | 42 CLIP (LOOP) | 10 | |
| 0993001 | 43 CLIP | 1 | |
| 1305300 | 44 CLIP | 1 | |
| 1488311 | 45 ADAPTER AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 8T1715 | ADAPTER | 1 | |
| 1497738 | 46 CLIP (LOOP) | 2 | |
| 1594724 | 47 VALVE-BALL | 2 | |
| 1644227 | 48 CLIP | 2 | |
| 1765868 | 49 ADAPTER | 1 | |
| 1984777 | 50 WASHER-HARD (11X25X10-MM THK) | 8 | |
| 1R0755 | 51 FILTER-FUEL (ADVANCED EFFICIENCY) | 1 | |
| 2042281 | 52 STRAP-CABLE | 2 | |
| 2256948 | 53 SEAL-O-RING | 6 | |
| 2287092 | 54 SEAL-O-RING | 6 | |
| 2287093 | 55 SEAL-O-RING | 1 | |
| 2385082 | 56 SEAL-O-RING | 1 | |
| 2815930 | 57 REDUCER AS | 1 | |
| 6V8946 | REDUCER | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2815979 | 58 ELBOW AS | 3 | |
| 6V9007 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 2860693 | 59 SPACER (11X25X18-MM THK) | 1 | |
| 2M9780 | 60 SEAL-O-RING | 4 | |
| 3095133 | 61 PLUG AS | 1 | |
| 9S4181 | PLUG (1-5/16-12-THD) | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3196219 | 62 ELBOW AS | 4 | |
| 6V9005 | ELBOW | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3218649 | 65 VALVE AS-FLUID SAMPLING | 1 | |
| 8C3446 | VALVE-SAMPLING | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3309726 | 66 PLUG AS | 4 | |
| 2270136 | PLUG | 1 | |
| 2287105 | SEAL-O-RING | 1 | |
| 3445675 | 67 NUT (M10X1.5-THD) | 4 | |
| 3E4353 | 68 WASHER-HARD (11X25X3-MM THK) | 2 | |
| 4392896 | 69 SPACER (11.5X20X30-MM THK) | 1 | |
| 4701669 | 70 HOSE AS | 1 | |
| 4701670 | 71 HOSE AS | 1 | |
| 4760001 | 72 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 4760012 | 73 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 1273387 | BOSS (M10X1.5X80-MM) | 1 | |
| 4832517 | 74 CLIP (LOOP) | 5 | |
| 5P7701 | 75 SEAL-O-RING | 1 | |
| 5P8182 | 76 GROMMET (46-MM ID) | 1 | |
| 6V1572 | 77 CLIP (SLOT) | 1 | |
| 6V1573 | 78 CLIP (TAB) | 1 | |
| 6V1867 | 79 CLIP (SLOT) | 1 | |
| 6V1868 | 80 CLIP (TAB) | 1 | |
| 6V1869 | 81 GROMMET (65-MM ID) | 1 | |
| 6V8640 | 82 CONNECTOR | 4 | |
| 6V9834 | 84 CAP | 1 | |
| 7D7233 | 85 CLIP (LOOP) | 8 | |
| 7X2539 | 86 BOLT (M8X1.25X110-MM) | 2 | |
| 7X7729 | 87 WASHER (11X25X3-MM THK) | 13 | |
| 8T1718 | 88 ELBOW | 1 | |
| 8T4121 | 89 WASHER-HARD (11X21X2.5-MM THK) | 31 | |
| 8T4133 | 90 NUT (M10X1.5-THD) | 14 | |
| 8T4137 | 91 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4182 | 92 BOLT (M10X1.5X45-MM) | 12 | |
| 8T4185 | 93 BOLT (M10X1.5X50-MM) | 1 | |
| 8T4195 | 94 BOLT (M10X1.5X30-MM) | 9 | |
| 8T4196 | 95 BOLT (M10X1.5X35-MM) | 9 | |
| 8T4198 | 96 BOLT (M10X1.5X100-MM) | 2 | |
| 8T4224 | 97 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T6466 | 98 BOLT (M10X1.5X60-MM) | 1 | |
| 8T6869 | 99 BOLT (M8X1.25X60-MM) | 3 | |
| 9N0869 | 100 WASHER-HARD (8.8X25.5X2-MM THK) | 6 |
