System And Components
461-8694 LINES GP-JACKET WATER HEATER -EXTENSIONAN ATTACHMENT
Group No: 461-8694
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4W2109 | 1 RETAINER | 4 | |
| 4W2110 | 2 RING-RETAINING | 2 | |
| 7N4945 | 3 GASKET | 2 | |
| 1343100 | 4 FLANGE | 2 | |
| 1531378 | 5 SPACER (13.8X25X20-MM THK) | 1 | |
| 4618695 | 6 TUBE AS | 1 | |
| 4618696 | 7 TUBE AS | 1 | |
| 0S1588 | 8 BOLT (3/8-16X1.25-IN) | 1 | |
| 0S1594 | 9 BOLT (3/8-16X1-IN) | 12 | |
| 1142687 | 10 SEAL-O-RING | 2 | |
| 3537952 | 11 GROMMET | 1 | |
| 5K9090 | 12 SEAL-O-RING (ORFS) | 2 | |
| 5M2894 | 13 WASHER-HARD (10.2X18.5X2.5-MM THK) | 5 | |
| 6K5535 | 14 CLIP (SLOT) | 1 | |
| 6K5536 | 15 CLIP (TAB) | 1 | |
| 6V9833 | 16 CAP | 2 | |
| 7X0328 | 17 BOLT (1/2-13X3.5-IN) | 1 | |
| 8T1897 | 18 CLIP (SLOT) | 1 | |
| 8T1898 | 19 CLIP (TAB) | 1 | |
| 8T7971 | 20 WASHER-HARD (13.5X25.5X5-MM THK) | 1 |
