System And Components
565-6033 LINES GP-FUEL INJECTIONS/N K1H1-UP
Group No: 565-6033
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P0692 | 1 CLAMP AS | 2 | |
| 1081434 | GROMMET | 1 | |
| 4P0693 | 2 CLAMP AS | 4 | |
| 1081434 | GROMMET | 2 | |
| 7C7683 | 3 ADAPTER-FUEL MANIFOLD (LH) | 1 | |
| 9Y0047 | 4 CLAMP | 1 | |
| 2815977 | 5 CONNECTOR AS | 6 | |
| 6V8642 | CONNECTOR | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3095137 | 6 CONNECTOR AS | 1 | |
| 6V8635 | CONNECTOR | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3196213 | 7 CONNECTOR AS | 1 | |
| 6V8634 | CONNECTOR | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3196217 | 8 CONNECTOR AS | 2 | |
| 6V8639 | CONNECTOR | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3196220 | 9 ELBOW AS | 2 | |
| 6V9008 | ELBOW | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3218618 | 10 CONNECTOR AS | 1 | |
| 9X2614 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 3218648 | 11 CONNECTOR AS | 2 | |
| 2T2991 | CONNECTOR | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385083 | SEAL-O-RING | 1 | |
| 3535096 | 12 CONNECTOR AS | 1 | |
| 8T9386 | CONNECTOR | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3676030 | 13 CONNECTOR AS | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3676029 | ADAPTER-STR | 1 | |
| 3717187 | 14 PLUG AS | 4 | |
| 2385083 | SEAL-O-RING | 1 | |
| 3603683 | PLUG | 1 | |
| 3893708 | 15 PLUG AS | 3 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3603679 | PLUG-CONNECTOR (9/16-18-THD) | 1 | |
| 3893709 | 16 PLUG AS | 3 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3603682 | PLUG-O-RING | 1 | |
| 3985601 | 17 PLUG AS | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3603681 | PLUG (7/8-14-THD) | 1 | |
| 4346464 | 18 VALVE GP-CHECK | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 4373327 | VALVE-CHECK | 1 | |
| 4400664 | 19 CLAMP | 1 | |
| 4597737 | 20 BLOCK | 1 | |
| 4604072 | 21 TUBE AS | 1 | |
| 4604074 | 22 TUBE AS | 1 | |
| 4679109 | 23 TUBE AS | 1 | |
| 4679110 | 24 TUBE AS | 1 | |
| 4708630 | 25 HOSE AS | 1 | |
| 4823479 | 26 HOSE AS | 1 | |
| 4878050 | 27 HOSE & TUBE AS | 1 | |
| 4881849 | 28 ADAPTER AS | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 4881848 | ADAPTER-CROSS | 1 | |
| 4944921 | 29 HOSE AS | 1 | |
| 5157738 | 30 HOSE AS | 1 | |
| 5219207 | 31 HOSE AS | 1 | |
| 5246577 | 32 HOSE AS | 1 | |
| 5435299 | 33 TUBE AS | 1 | |
| 5444142 | 34 TUBE AS | 1 | |
| 1003237 | 35 GROMMET | 4 | |
| 1997854 | 36 SPACER (11.8X20X45-MM THK) | 1 | |
| 2287090 | 37 SEAL-O-RING | 2 | |
| 2287091 | 38 SEAL-O-RING | 4 | |
| 2287105 | 39 SEAL-O-RING | 2 | |
| 2815975 | 40 ELBOW AS | 2 | |
| 6V8626 | ELBOW | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3309726 | 41 PLUG AS | 2 | |
| 2270136 | PLUG | 1 | |
| 2287105 | SEAL-O-RING | 1 | |
| 3328562 | 42 ELBOW AS | 3 | |
| 6V9852 | ELBOW (SWIVEL) | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 3E4353 | 43 WASHER-HARD (11X25X3-MM THK) | 2 | |
| 4708640 | 44 HOSE AS | 1 | |
| 4H7655 | 45 CLAMP-TUBE | 2 | |
| 5661862 | 46 TEE AS | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 5656297 | TEE | 1 | |
| 5667799 | 47 HOSE AS | 1 | |
| 5P8245 | 48 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 6B6205 | 49 SPACER (0.438X0.875X1.281-IN THK) | 2 | |
| 6V5230 | 50 BOLT (M10X1.5X60-MM) | 1 | |
| 6V5815 | 51 BOLT (M10X1.5X75-MM) | 1 | |
| 6V5839 | 52 WASHER (11X21X2.5-MM THK) | 4 | |
| 6V5842 | 53 BOLT (M10X1.5X40-MM) | 1 | |
| 6V7673 | 54 BOLT (M12X1.75X50-MM) | 1 | |
| 6V7981 | 55 BOLT (M10X1.5X70-MM) | 1 | |
| 8T0100 | 57 BOLT (M8X1.25X60-MM) | 1 | |
| 8T0644 | 58 BOLT (M10X1.5X90-MM) | 2 | |
| 8T4121 | 59 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T5436 | 60 BOLT (M10X1.5X130-MM) | 2 | |
| 8T7491 | 61 CONNECTOR | 2 | |
| 9M1974 | 62 WASHER-HARD (8.8X16X2-MM THK) | 1 |
