System And Components
511-5018 PUMP GP-FUELS/N HRT1-UP
Group No: 511-5018
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2435739 | 1 SEAL | 2 | |
| 7E8716 | 2 CAP/PLUG-TAPERED | 4 | |
| 9U7070 | 3 CAP/PLUG-TAPERED | 1 | |
| 3218643 | 4 PLUG AS | 1 | |
| 9G7132 | PLUG-ORIFICE | 1 | |
| 2385078 | SEAL-O-RING | 1 | |
| 3812621 | 5 MOUNTING-CABLE TIE | 1 | |
| 4190422 | 6 BRACKET | 1 | |
| 4498530 | 7 HARNESS AS-PUMP | 1 | |
| 1779656 | KIT-CONNECTING PLUG (4-PIN) | 2 | |
| 8T8737 | PLUG-SEAL | 2 | |
| 3E5226 | SOCKET-CONNECTOR (12-GA TO 14-GA) | 6 | |
| 4500243 | 8 PUMP GP-FUEL | 1 | |
| 8T4908 | 9 BOLT (M8X1.25X25-MM) | 3 | |
| 4500247 | 10 MANIFOLD AS | 1 | |
| 2287097 | SEAL-O-RING | 1 | |
| 2435739 | SEAL | 2 | |
| 2609188 | PLUG | 1 | |
| 8T5005 | 11 BOLT (M10X1.5X70-MM) | 2 | |
| 4500339 | 12 COVER-PUMP | 1 | |
| 8T6685 | 13 BOLT (M10X1.5X110-MM) | 2 | |
| 8T7547 | 14 BOLT (M8X1.25X30-MM) | 1 | |
| 4575704 | 15 MANIFOLD | 1 | |
| 0993649 | 16 BOLT (M8X1.25X40-MM) | 1 | |
| 1309474 | 17 SEAL-O-RING | 2 | |
| 1325789 | 18 CLIP (LADDER) | 1 | |
| 1364184 | 19 BOLT-SOCKET HEAD (M8X1.25X40-MM) | 3 | |
| 1779653 | 20 KIT-RECEPTACLE (4-PIN) | 1 | |
| 1838004 | 21 BOLT-SOCKET HEAD (M10X1.5X180-MM) | 1 | |
| 2042281 | 22 STRAP-CABLE | 1 | |
| 2048000 | 23 MOUNTING-CABLE TIE | 1 | |
| 3445675 | 24 NUT (M10X1.5-THD) | 4 | |
| 3E6787 | 25 SEAL-O-RING | 1 | |
| 8L8413 | 26 STRAP-CABLE (WHITE) | 1 | |
| 8T4121 | 27 WASHER-HARD (11X21X2.5-MM THK) | 17 | |
| 8T4136 | 28 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4186 | 29 BOLT (M10X1.5X40-MM) | 1 | |
| 8T4198 | 30 BOLT (M10X1.5X100-MM) | 6 | |
| 8T4224 | 31 WASHER-HARD (8.8X16X2-MM THK) | 8 |
