System And Components
516-7970 CABLE GP-GROUNDS/N MFJ1-UP
Group No: 516-7970
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4182 | 1 BOLT (M10X1.5X45-MM) | 4 | |
| 7X2543 | 2 BOLT (M10X1.5X120-MM) | 1 | |
| 8T4172 | 3 BOLT (M10X1.5X80-MM) | 1 | |
| 8T4198 | 4 BOLT (M10X1.5X100-MM) | 2 | |
| 1321805 | 5 STRAP AS-GROUND | 1 | |
| 1997854 | 6 SPACER (11.8X20X45-MM THK) | 1 | |
| 2G8767 | 7 WASHER (10.5X60X3-MM THK) | 10 | |
| 3068526 | 8 GROMMET | 1 | |
| 3280132 | 9 CABLE AS | 1 | |
| 8C5918 | TERMINAL AS-BATTERY (NEGATIVE) | 1 | |
| 8T9756 | TERMINAL AS-BATTERY (POSITIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 9G0002 | COVER AS-TERMINAL (RED) | 1 | |
| 9G0005 | COVER AS-TERMINAL (BLACK) | 1 | |
| 8L8413 | STRAP-CABLE (WHITE) | 1 | |
| 1598049 | CABLE (00-GA, RED)(31-CM) | ||
| 4837805 | 10 SPACER (11X20X65-MM THK) | 2 | |
| 4841451 | 11 CLIP | 7 | |
| 4841456 | 12 STRAP-CABLE | 6 | |
| 5177927 | 13 CABLE AS-GROUND | 1 | |
| 6V2722 | TUBE-HEAT SHRINK (25.4-MM DIA)(0.1-M) | ||
| 1S7252 | TERMINAL-CABLE (00-GA, 3/8-IN SCREW) | 2 | |
| 1598050 | CABLE (00-GA, BLACK)(28-CM) | ||
| 5192509 | 14 HARNESS AS-WIRING | 1 | |
| 3S6050 | TERMINAL AS-BATTERY (NEGATIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 1S7252 | TERMINAL-CABLE (00-GA, 3/8-IN SCREW) | 1 | |
| 6T0465 | COVER-TERMINAL (BLACK) | 1 | |
| 7N5274 | COVER AS-TERMINAL (BLACK) | 1 | |
| 8L8413 | STRAP-CABLE (WHITE) | 1 | |
| 1598050 | CABLE (00-GA, BLACK)(114-CM) | ||
| 2042281 | STRAP-CABLE | 2 | |
| 4841452 | CLIP | 2 | |
| 5192511 | 15 CABLE AS (FUSE) | 1 | |
| 6V2722 | TUBE-HEAT SHRINK (25.4-MM DIA)(0.1-M) | ||
| 0301705 | TERMINAL-CABLE (00-GA, 5/16-IN SCREW) | 2 | |
| 1598049 | CABLE (00-GA, RED)(41-CM) | ||
| 5192513 | 16 CABLE AS (ALTERNATOR) | 1 | |
| 8T8827 | BOOT (RED) | 1 | |
| 0301708 | TERMINAL-RING (0-GA) | 2 | |
| 1257876 | TUBE-HEAT SHRINK (17.78-MM DIA)(4-CM) | ||
| 1598047 | CABLE-ELECTRICAL (0-GA, RED)(278-CM) | ||
| 2042281 | STRAP-CABLE | 1 | |
| 4841452 | CLIP | 1 | |
| 5192514 | 17 CABLE AS (ALTERNATOR) | 1 | |
| 0301708 | TERMINAL-RING (0-GA) | 1 | |
| 1257876 | TUBE-HEAT SHRINK (17.78-MM DIA)(4-CM) | ||
| 1598047 | CABLE-ELECTRICAL (0-GA, RED)(241-CM) | ||
| 2042281 | STRAP-CABLE | 1 | |
| 2996082 | COVER-TERMINAL (RED) | 1 | |
| 4841452 | CLIP | 1 | |
| 5192515 | 18 CABLE AS (ALTERNATOR) | 1 | |
| 6V2722 | TUBE-HEAT SHRINK (25.4-MM DIA)(0.1-M) | ||
| 0301709 | TERMINAL-RING (0-GA, 1/4-IN SCREW) | 2 | |
| 1598048 | CABLE-ELECTRICAL (0-GA, BLACK)(28-CM) | ||
| 5192516 | 19 STRAP AS-GROUND | 1 | |
| 0319295 | TERMINAL-RING (0000-GA, 3/8-IN SCREW) | 1 | |
| 5439537 | 20 BRACKET AS-FAN | 1 | |
| 5514239 | 21 CABLE AS-STARTER | 1 | |
| 6V2722 | TUBE-HEAT SHRINK (25.4-MM DIA)(0.1-M) | ||
| 1S7252 | TERMINAL-CABLE (00-GA, 3/8-IN SCREW) | 1 | |
| 8N0869 | COVER-TERMINAL (RED) | 1 | |
| 0301705 | TERMINAL-CABLE (00-GA, 5/16-IN SCREW) | 1 | |
| 1598049 | CABLE (00-GA, RED)(231-CM) | ||
| 2042281 | STRAP-CABLE | 1 | |
| 4841452 | CLIP | 1 | |
| 5625622 | 22 BRACKET AS | 1 | |
| 5633426 | 23 CABLE AS | 1 | |
| 6V2722 | TUBE-HEAT SHRINK (25.4-MM DIA)(0.1-M) | ||
| 8T9756 | TERMINAL AS-BATTERY (POSITIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 9G0002 | COVER AS-TERMINAL (RED) | 1 | |
| 8L8413 | STRAP-CABLE (WHITE) | 1 | |
| 0301705 | TERMINAL-CABLE (00-GA, 5/16-IN SCREW) | 1 | |
| 1598049 | CABLE (00-GA, RED)(79-CM) | ||
| 2042281 | STRAP-CABLE | 2 | |
| 4841452 | CLIP | 2 | |
| 5C7261 | 24 NUT (M8X1.25-THD) | 2 | |
| 6G2256 | 25 CLAMP | 8 | |
| 6G2263 | 26 SPACER (10.5X19X28.5-MM THK) | 8 | |
| 8T1889 | 27 CLIP (SLOT) | 1 | |
| 8T1890 | 28 CLIP (TAB) | 1 | |
| 8T4121 | 29 WASHER-HARD (11X21X2.5-MM THK) | 13 | |
| 8T4136 | 30 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4137 | 31 BOLT (M10X1.5X20-MM) | 10 | |
| 8T4171 | 32 BOLT (M6X1X12-MM) | 1 | |
| 9X8256 | 33 WASHER (6.6X12X2-MM THK) | 1 |
