System And Components
428-8558 LINES GP-FUEL INJECTIONS/N M631-UP
Group No: 428-8558
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P0692 | 1 CLAMP AS | 8 | |
| 1081434 | GROMMET | 1 | |
| 4P0693 | 2 CLAMP AS | 4 | |
| 1081434 | GROMMET | 2 | |
| 7C7677 | 3 TUBE AS | 12 | |
| 7C7678 | 4 TUBE AS | 12 | |
| 7C7682 | 5 ADAPTER-FUEL MANIFOLD (RH) | 1 | |
| 7C7683 | 6 ADAPTER-FUEL MANIFOLD (LH) | 1 | |
| 7W2122 | 7 CONNECTOR-PORT | 24 | |
| 9N4053 | 8 SPRING | 1 | |
| 1113389 | 9 TUBE AS | 1 | |
| 1145477 | 10 PLUNGER-VALVE | 1 | |
| 1189485 | 11 TUBE AS | 1 | |
| 1569753 | 12 MANIFOLD GP-FUEL (RH) | 1 | |
| 1569754 | 13 MANIFOLD GP-FUEL (LH) | 1 | |
| 2348728 | 14 TUBE AS | 1 | |
| 2609152 | 15 VALVE-CHECK (FUEL) | 1 | |
| 2673398 | 16 TUBE AS | 1 | |
| 2749855 | 17 BRACKET | 1 | |
| 2815976 | 18 ELBOW AS | 1 | |
| 6V8629 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 2815978 | 19 CONNECTOR AS | 1 | |
| 6V8640 | CONNECTOR | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 2837192 | 20 TUBE AS | 1 | |
| 3650576 | 21 CONNECTOR AS | 2 | |
| 9M4584 | CONNECTOR | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3866229 | 22 ELBOW AS | 2 | |
| 2385081 | SEAL-O-RING | 1 | |
| 2501497 | ELBOW | 1 | |
| 4391889 | 23 ELBOW AS | 1 | |
| 1292327 | ELBOW | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 0038581 | 24 TEE-UNION | 1 | |
| 0307959 | 25 TEE-FLARED | 1 | |
| 0L1143 | 26 BOLT (3/8-16X2.5-IN) | 1 | |
| 0L1352 | 27 BOLT (3/8-16X3.25-IN) | 2 | |
| 0L2070 | 28 BOLT (3/8-16X2.25-IN) | 1 | |
| 0T0065 | 29 BOLT (3/8-16X3.5-IN) | 2 | |
| 1D4539 | 30 BOLT (5/16-18X2.5-IN) | 1 | |
| 1D4541 | 31 BOLT (5/16-18X3-IN) | 1 | |
| 2147566 | 32 SEAL-O-RING | 1 | |
| 2147568 | 33 SEAL-O-RING | 24 | |
| 2385080 | 34 SEAL-O-RING | 1 | |
| 2385081 | 35 SEAL-O-RING | 1 | |
| 3510258 | 36 ELBOW AS | 1 | |
| 1P7625 | ELBOW | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3650578 | 37 CONNECTOR AS | 1 | |
| 2P7636 | CONNECTOR (3/4-16 STR-THD) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 5M2894 | 38 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 5S0003 | 39 NUT (5/16-18-THD) | 1 | |
| 4P0489 | 40 SPACER (11X25X26.8-MM THK) | 2 | |
| 6V9012 | 41 CONNECTOR | 1 | |
| 9X6458 | 42 WASHER-HARD (10.2X22.5X3-MM THK) | 1 | |
| 7K3377 | 43 PIPE | 2 | |
| 7N6806 | 44 SEAL-RECTANGULAR | 4 | |
| 9M1974 | 45 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 9S4182 | 46 PLUG (7/16-20-THD) | 1 | |
| 9S8752 | 47 NUT-FULL (3/8-16-THD) | 1 |
