System And Components
9U-9028 VALVE GP-PRESSURE CONTROL -CLUTCH OIL FLOWS/N 8KA4000-UP
Group No: 9U-9028
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4948052 | 1 BODY AS | 1 | |
| 6F4863 | 1A PIN-GROOVED | 4 | |
| 5S7906 | 1B STOP | 4 | |
| 8P7385 | 1C BODY-VALVE | 1 | |
| 5M2504 | 3 SLUG | 7 | |
| 9P0683 | 4 SPRING | 7 | |
| 9P0656 | 6 SPOOL AS | 7 | |
| 4B9880 | 6A BALL | 1 | |
| 4M2381 | 6B SPRING | 1 | |
| 1S1636 | 6C RETAINER | 1 | |
| 1S1638 | 6D RING-RETAINING | 1 | |
| 6T2293 | 7 PISTON-LOAD | 3 | |
| 9W7411 | 8 SPRING (YELLOW) | 4 | |
| 3T1437 | 9 PISTON-LOAD | 1 | |
| 0S1614 | 10 BOLT (1/4-20X0.5-IN) | 1 | |
| 8E4592 | 11 STOP | 7 | |
| 1607578 | 12 BODY-LOAD PISTON | 7 | |
| 7S4594 | 13 PISTON-LOAD | 1 | |
| 4M1751 | 14 SPACER (15.09X0.4-MM THK) | 14 | |
| 5J2721 | 15 SHIM (0.13-MM THK) | 14 | |
| 6J3993 | 16 SHIM (0.25-MM THK) | 14 | |
| 5J1036 | 17 SHIM (0.8-MM THK) | 35 | |
| 7G7431 | 18 PISTON-SELECTOR | 7 | |
| 7T0571 | 19 SPRING (GREEN) | 2 | |
| 9P0687 | 20 PISTON-LOAD | 3 | |
| 9W7410 | 21 SPRING (BLUE) | 1 | |
| 3218641 | 23 PLUG AS | 14 | |
| 9S8001 | PLUG (5/16-24-THD) | 1 | |
| 2385078 | SEAL-O-RING | 1 | |
| 9W7412 | 24 SPRING (LT GREEN) | 2 | |
| 8L2777 | 25 SEAL-O-RING | 7 | |
| 9D7884 | 26 SPRING | 7 | |
| 5P9287 | 27 WASHER-HARD (7.2X32X2-MM THK) | 1 | |
| 5L9018 | 28 BOLT-SOCKET HEAD (1/4-20X1.75-IN) | 14 | |
| 7T0570 | 29 SPRING (ORANGE) | 2 | |
| 7T0569 | 30 SPRING (LT BLUE) | 3 | |
| 3706344 | 31 ORIFICE AS | 2 | |
| 3706345 | 32 ORIFICE AS | 5 | |
| 3133492 | 33 PLUG AS | 2 | |
| 9S4190 | PLUG-O-RING (7/8-14-THD) | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3378780 | 34 PLUG AS | 3 | |
| 9G7131 | PLUG-ORIFICE | 1 | |
| 2385078 | SEAL-O-RING | 1 | |
| 3218643 | 35 PLUG AS | 3 | |
| 9G7132 | PLUG-ORIFICE | 1 | |
| 2385078 | SEAL-O-RING | 1 | |
| 7G2674 | 36 PIN | 2 | |
| 5P0537 | 37 WASHER-HARD (7.2X14.5X2-MM THK) | 14 |
