System And Components
8N-5743 DRIVE GP-ACCESSORY -UPPER, LHREVERSE ROTATION
Group No: 8N-5743
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5R7136 | 1 WASHER-SEALING | 1 | |
| 5R7137 | 2 WASHER-SEALING | 2 | |
| 7C3258 | 3 WASHER AS-THRUST | 1 | |
| 7N2047 | DOWEL | 1 | |
| 7C3260 | 4 SHAFT | 1 | |
| 7E0275 | 5 GEAR-WATER PUMP DRIVE (69-TEETH) | 1 | |
| 7N5279 | 6 ADAPTER AS | 1 | |
| 1275400 | 6A BUSHING | 1 | |
| 7N5874 | 7 SHAFT-AUXILIARY DRIVE (14-TEETH) | 1 | |
| 7N7539 | 8 WASHER-THRUST | 2 | |
| 7N8374 | 9 COVER-PUMP | 2 | |
| 4413369 | 10 ADAPTER AS | 1 | |
| 1275400 | 10A BUSHING | 1 | |
| 1448263 | 11 GEAR AS-IDLER (53-TEETH) | 1 | |
| 1409597 | 11A BUSHING | 1 | |
| 2353546 | 12 SEAL-O-RING | 1 | |
| 2594598 | 13 SEAL-O-RING | 2 | |
| 0S1592 | 14 BOLT (5/8-11X1.25-IN) | 4 | |
| 3B1915 | 15 BOLT (3/8-16X1.375-IN) | 6 | |
| 0T0055 | 16 BOLT (3/8-16X4.25-IN) | 1 | |
| 1T0765 | 17 BOLT (3/8-16X1-IN) | 6 | |
| 2B2695 | 19 BOLT (5/16-18X0.875-IN) | 4 | |
| 5M2894 | 20 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 5P0840 | 21 SEAL-O-RING | 1 | |
| 5P8245 | 22 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 5P8247 | 23 WASHER-HARD (17X32X3.5-MM THK) | 4 | |
| 6K3772 | 24 BOLT-12 POINT HEAD (7/16-14X2.25-IN) | 12 | |
| 6V3348 | 25 SEAL-O-RING | 1 | |
| 8T6757 | 26 PLUG-PIPE | 2 | |
| 8T6759 | 27 PLUG-PIPE | 2 | |
| 9M1974 | 28 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 6V8260 | 29 SEAL-O-RING | 2 | |
| 1D4572 | 30 BOLT (1/2-13X5.5-IN) | 2 |
