Assembly
100%

7W-7214 GUARD GP-BELT -FANAN ATTACHMENT

Group No: 7W-7214
Part NumberPart NameQty
3B86861 FITTING-GREASE (1/8-27 PTF)1
4B45502 FITTING-PRESSURE RELIEF (1/8-27 PTF)1
7C05513 PLATE AS1
7C14614 GUARD AS1
4K9097NUT-WELD (5/16-18-THD)8
7C14645 GUARD (LH)1
7C14656 GUARD AS (RH)1
4K9097NUT-WELD (5/16-18-THD)1
7W72167 BRACKET AS2
4K9097NUT-WELD (5/16-18-THD)2
7W72188 BRACKET AS1
4K9097NUT-WELD (5/16-18-THD)4
0S05099 BOLT (3/8-16X0.75-IN)2
0S162110 BOLT (1/2-13X1-IN)4
2A463911 BOLT (3/8-16X1.625-IN)2
2H375512 BOLT (5/16-18X0.43-IN)15
3B882213 ELBOW2
5P107514 WASHER-HARD (10.2X22.5X3-MM THK)4
5P107615 WASHER-HARD (13.5X30X4-MM THK)4
5P411616 WASHER-HARD (8.8X20.5X2-MM THK)15
8L655717 CONNECTOR2
3N462218 HOSE AS2
