System And Components
2W-8331 CARTRIDGE GP-TURBOCHARGERPART OF 4W-9058 TURBOCHARGER GP
Group No: 2W-8331
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W1940 | 1 WASHER-RETAINING | 1 | |
| 2W1241 | 2 RING-CARRIER | 1 | |
| 2W1249 | 3 RING-RETAINING | 1 | |
| 2W1349 | 4 INSERT-COMPRESSOR | 1 | |
| 6V6353 | 5 SEAL-O-RING | 1 | |
| 2W1350 | 6 SHROUD-HEAT | 1 | |
| 2W1267 | 7 SHROUD-HEAT | 1 | |
| 2W1233 | 8 BEARING-JOURNAL | 2 | |
| 2W1234 | 9 RING-SEAL | 1 | |
| 2W8332 | 10 WHEEL & SHAFT AS | 1 | |
| 2W1984 | 11 RING-RETAINING | 4 | |
| 2W1261 | 12 HOUSING-BEARING | 1 | |
| 2W1250 | 13 RING-THRUST | 1 | |
| 2W1231 | 14 BEARING-THRUST | 1 | |
| 2W1232 | 15 RING-THRUST | 1 | |
| 2W1240 | 16 RING-SEAL | 1 | |
| 2W7222 | 17 WHEEL-COMPRESSOR | 1 | |
| 2W1268 | 18 LOCKNUT (M14X1.5-THD) | 1 | |
| 8H3128 | 19 BOLT-SOCKET HEAD (1/4-20X0.625-IN) | 3 | |
| 3B4504 | LOCKWASHER | 3 | |
| 6L2244 | 20 PIN | 1 | |
| 4W5736 | CARTRIDGE GP-TURBOCHARGER | 1 |
