System And Components
7E-0687 CARTRIDGE GP-TURBOCHARGERPART OF 140-3136, 7E-0679 TURBOCHARGER GP
Group No: 7E-0687
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W1940 | 1 WASHER-RETAINING | 1 | |
| 7E0688 | 2 RING-SEAL | 1 | |
| 3J1577 | 3 RING-RETAINING (INTERNAL) | ||
| 7E0689 | 4 COVER | 1 | |
| 6V6353 | 5 SEAL-O-RING | 1 | |
| 2W1350 | 6 SHROUD-HEAT | 1 | |
| 7E0690 | 7 SHIELD | 1 | |
| 2W1233 | 8 BEARING-JOURNAL | 2 | |
| 2W1234 | 9 RING-SEAL | 1 | |
| 7E0697 | 10 WHEEL & SHAFT AS | 1 | |
| 2W1984 | 11 RING-RETAINING | 4 | |
| 7E0694 | 12 HOUSING-BEARING | 1 | |
| 2W1250 | 13 RING-THRUST | 1 | |
| 7E0693 | 14 BEARING-THRUST | 1 | |
| 7E0691 | 15 RING-FLINGER | 1 | |
| 2W1240 | 16 RING-SEAL | 1 | |
| 7W3519 | 17 WHEEL-COMPRESSOR | 1 | |
| 2W1268 | 18 LOCKNUT (M14X1.5-THD) | 1 | |
| 8H3128 | 19 BOLT-SOCKET HEAD (1/4-20X0.625-IN) | 3 | |
| 3B4504 | LOCKWASHER | 3 | |
| 6L2244 | 20 PIN | 1 | |
| 4W5736 | CARTRIDGE GP-TURBOCHARGER | 1 | |
| 7E0692 | KIT-TURBOCHARGER REPAIR (COMPRESSOR OIL SEAL) | 1 |
