System And Components
7C-3824 CARTRIDGE GP-TURBOCHARGERPART OF 7C-3821 TURBOCHARGER GP
Group No: 7C-3824
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7C3826 | 1 WHEEL-COMPRESSOR | 1 | |
| 7N3759 | 2 RING-PISTON | 1 | |
| 9N2046 | 3 SPACER-THRUST | 1 | |
| 6N5004 | 4 BEARING-THRUST | 1 | |
| 9M8911 | 5 COLLAR-THRUST | 1 | |
| 9M8919 | 6 RING-SEAL | 2 | |
| 1P1120 | 7 RING-SEAL | 1 | |
| 9M8915 | 8 RING-RETAINING | 3 | |
| 1S1770 | 9 LOCKNUT-TURBOCHARGER | 1 | |
| 9N2036 | 10 PLATE-LOCK | 4 | |
| 0S1616 | 11 BOLT (1/4-20X1-IN) | 4 | |
| 2W4130 | 12 PLATE AS-BACKING | 1 | |
| 9N2035 | 13 HOUSING AS-CENTER | 1 | |
| 2W4131 | 14 WHEEL & SHAFT AS | 1 | |
| 4P6527 | 15 SHROUD (TURBINE) | 1 | |
| 9N2041 | KIT-BEARING | 1 | |
| 7C7447 | KIT-BEARING (0.51-MM OS, 0.25-MM US) | ||
| 7C7446 | KIT-BEARING (0.51-MM OS) | ||
| 7N3194 | KIT-BEARING (0.25-MM OS, 0.25-MM US) | ||
| 8N4157 | KIT-BEARING (0.25-MM OS) | ||
| 8N4160 | KIT-BEARING (0.25-MM US) | ||
| 2W0715 | KIT-CARTRIDGE (TURBOCHARGER) | 1 |
