System And Components
7C-1312 LINES GP-TURBOCHARGER AIR
Group No: 7C-1312
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W4067 | 1 PIPE | 1 | |
| 2W4068 | 2 PIPE | 1 | |
| 5P5700 | 3 SEAL-O-RING | 4 | |
| 5N4432 | 4 BOOT | 2 | |
| 6V2695 | 5 SEAL-O-RING | 4 | |
| 7N4897 | 6 FLANGE | 2 | |
| 7N4895 | 7 GASKET | 2 | |
| 5P3860 | 8 CLAMP-HOSE | 2 | |
| 0L1329 | 9 BOLT (1/2-13X3-IN) | 2 | |
| 5M2894 | 11 WASHER-HARD (10.2X18.5X2.5-MM THK) | 88 | |
| 0L1143 | 12 BOLT (3/8-16X2.5-IN) | 6 | |
| 1343804 | 14 ELBOW | 8 | |
| 7N5085 | 15 FLANGE | 8 | |
| 7N5080 | 16 GASKET-MANIFOLD | 8 | |
| 5P0076 | 17 BOLT-12 POINT HEAD (3/8-16X1.5-IN) | 64 | |
| 7N5089 | 19 GASKET | 8 | |
| 6V5101 | 20 SEAL-O-RING | 8 | |
| 2W1640 | 21 BRACKET | 1 | |
| 1400407 | 22 ELBOW-EXHAUST | 1 | |
| 3J5389 | 23 PLUG (EXTERNAL) | 2 | |
| 4W0716 | 24 MANIFOLD-AIR INLET | 1 | |
| 1A2029 | 25 BOLT (3/8-16X1.125-IN) | 16 | |
| 0S1571 | 26 BOLT (3/8-16X1.75-IN) | 2 | |
| 1W1251 | 27 GASKET | 2 | |
| 5P8245 | 29 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 4P8097 | 30 BRACKET | 2 | |
| 8T6765 | 31 PLUG-PIPE (1/4-18-THD) | 3 | |
| 9S8752 | 32 NUT-FULL (3/8-16-THD) | 2 | |
| 0S0509 | 34 BOLT (3/8-16X0.75-IN) | 2 | |
| 9L9132 | 35 WASHER-HARD (10.2X25.5X2.5-MM THK) | 6 | |
| 0L1351 | 36 BOLT (3/8-16X0.875-IN) | 2 | |
| 7W1944 | 37 RETAINER | 2 |
