170-7572 MOTOR GP-TRAVELS/N JCD1-UP; JNK1-UP

Group No: 170-7572

Part Number	Part Name	Qty
1T0936	1 PLUG-ORIFICE	2
4B4158	2 SCREW-DRIVE (NO 4X0.25-IN)	4
6V3382	3 SEAL-LIP TYPE	1
8J2559	4 PLATE-WARNING (OIL FILL)	1
1185805	5 BEARING-SPECIAL RACE	1
1241530	6 BARREL AS	1
1241535	7 PLATE	1
1241536	8 DISC-FRICTION	5
1241537	9 PLATE-SEPARATOR	6
1241538	10 PISTON-BRAKE	1
1241541	11 PIN	2
1757887	12 DOWEL	2
1241554	13 SPRING	1
1241557	14 RETAINER	2
1241561	15 SPRING-BRAKE	20
1241562	16 VALVE GP-SPEED CONTROL	1
0336027	SEAL-O-RING	1
1264002	17 SEAL-O-RING	2
1264003	18 SEAL-O-RING	1
1264004	19 RING-BACKUP	1
1264040	20 RING-BACKUP	1
1353859	21 SPACER (70.4X80X1.57-MM THK)	1
1375646	22 SPACER (70.4X87.5X7.6-MM THK)	1
1437140	23 KEY	2
1465772	24 WASHER-SPRING	4
1483548	25 BEARING-SPECIAL RACE	1
1491207	26 PLATE	1
1510267	27 SHAFT	1
1546211	28 BALL	1
1554897	29 PISTON AS	9
1597320	30 PLATE-RETAINER	1
1707575	31 PLATE-CAM	1
1708747	32 PISTON	1
1791929	33 HEAD AS	1
1791930	34 BODY AS	1
1954456	35 PLUG-ORIFICE	1
0951572	36 SEAL-O-RING	2
0965919	37 RING-BACKUP	2
1437319	38 RACE-ROLLER BEARING	1
2013203	39 PIN	3
2A3630	40 PIN	1
2D6642	41 BALL	2
2R1236	42 RING-RETAINING (LOCK, INTERNAL)	1
3D2824	43 SEAL-O-RING	2
3K0360	44 SEAL-O-RING	3
5B9318	45 BALL	1
5P7684	46 PLUG	1
6K6307	47 SEAL-O-RING	1
7Y5219	48 SEAL-O-RING	2
8T4187	49 BOLT (M20X2.5X80-MM)	6
9S4183	50 PLUG (1-1/16-12-THD)	2
9S4185	51 PLUG (3/4-16-THD)	3
1802630	KIT-SEAL (TRAVEL MOTOR)	1
1259571	KIT-SEAL (TRAVEL MOTOR)	1
