System And Components
308-5694 AIR COMPRESSOR GPTU-FLO 750
Group No: 308-5694
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P5106 | 1 BRACKET | 1 | |
| 6B6682 | 2 NUT-FULL (3/4-16-THD) | 1 | |
| 7C3179 | 3 GEAR (50-TEETH) | 1 | |
| 0907055 | 4 HOSE AS | 1 | |
| 1359819 | 5 SEAL-INTEGRAL | 1 | |
| 1647559 | 6 AIR COMPRESSOR GP | 1 | |
| 1833406 | 7 PLUG AS | 1 | |
| 6V5049 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 3085695 | 8 HOSE AS | 1 | |
| 0016936 | 9 ELBOW | 1 | |
| 1488408 | 10 PLUG AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 9S4183 | PLUG (1-1/16-12-THD) | 1 | |
| 2N1287 | 11 ELBOW-FLARED | 1 | |
| 2P7636 | 12 CONNECTOR (3/4-16 STR-THD) | 1 | |
| 3K0360 | 13 SEAL-O-RING | 1 | |
| 5P8245 | 14 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 6V5049 | 15 SEAL-O-RING | 1 | |
| 6V5696 | 16 BOLT (M12X1.75X80-MM) | 2 | |
| 7J4026 | 17 ELBOW | 1 | |
| 7X0521 | 18 WASHER-HARD (20X36.5X5-MM THK) | 1 | |
| 8T4121 | 19 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4136 | 20 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4195 | 21 BOLT (M10X1.5X30-MM) | 2 | |
| 8T6764 | 22 PLUG-PIPE (1/8-27-THD) | 1 |
