System And Components
310-1967 AIR COMPRESSOR GPFOR USE WITH WET ACERT SEPARATE CIRCUIT AFTERCOOLER
Group No: 310-1967
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5L5012 | 1 V-BELT SET (INCLUDES 2-BELTS)(ALTERNATOR) | 1 | |
| 6N8643 | 2 PULLEY-AIR COMPRESSOR (1-GROOVE) | 1 | |
| 6N9042 | 3 GASKET | 1 | |
| 1228966 | 4 AIR COMPRESSOR GP | 1 | |
| 1314871 | 5 SUMP-COMPRESSOR | 1 | |
| 2911905 | 6 BRACKET AS | 1 | |
| 3236396 | 8 BRACKET AS | 1 | |
| 1M0644 | 9 BOLT (3/8-16X2.25-IN) | 1 | |
| 2S0932 | 10 WASHER-HARD (12X28.5X5-MM THK) | 4 | |
| 3S1546 | 11 NUT-FULL (7/16-14-THD) | 4 | |
| 4F5192 | 12 BOLT (7/16-14X3-IN) | 4 | |
| 4S9191 | 13 WASHER (12X22.5X5-MM THK) | 4 | |
| 5M2894 | 14 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 5P8245 | 15 WASHER-HARD (13.5X25.5X3-MM THK) | 12 | |
| 6L7283 | 16 BOLT (3/8-16X7-IN) | 1 | |
| 6V5684 | 17 BOLT (M12X1.75X45-MM) | 4 | |
| 6V8149 | 18 NUT (M12X1.75-THD) | 4 | |
| 6V8197 | 19 BOLT (M12X1.75X40-MM) | 4 | |
| 7X0591 | 20 WASHER-HARD (17X29X3-MM THK) | 3 | |
| 8T0299 | 21 BOLT (M16X2X30-MM) | 1 | |
| 8T4779 | 22 BOLT (M16X2X35-MM) | 3 | |
| 9S8752 | 23 NUT-FULL (3/8-16-THD) | 2 | |
| 3B4618 | 24 PIN-COTTER | 1 |
