System And Components
502-1490 CLUTCH GPPART OF 521-2316 POWER TAKE-OFF GP
Group No: 502-1490
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B8489 | 1 ADAPTER (1/8-27 PTF)(CLUTCH) | 2 | |
| 8B7121 | 2 FITTING-HYDRAULIC (CLUTCH) | 2 | |
| 2760744 | 3 CAP-PLUG | 2 | |
| 4900188 | 4 LINK | 8 | |
| 4904090 | 5 RING | 1 | |
| 4905402 | 6 LEVER-CLUTCH | 4 | |
| 4905442 | 7 PLATE | 1 | |
| 4908001 | 8 WASHER-SPRING | 8 | |
| 4920192 | 9 PLATE AS | 1 | |
| 4906496 | SPRING-PIN | 1 | |
| 4920193 | PIN | 1 | |
| 4920217 | 10 COLLAR AS-SLEEVE | 1 | |
| 0L1648 | BOLT (3/8-24X2.5-IN) | 2 | |
| 2L6267 | LOCKNUT (3/8-24-THD) | 2 | |
| 4920219 | 11 YOKE AS | 1 | |
| 3B4506 | LOCKWASHER | 2 | |
| 1653929 | BOLT (3/8-16X1.5-IN) | 2 | |
| 4920221 | 12 LEVER AS-HAND | 1 | |
| 0S1587 | BOLT (1/2-13X1.75-IN) | 1 | |
| 4920224 | 13 SHAFT-CLUTCH | 1 | |
| 5055753 | 14 CAP-GREASE | 4 | |
| 0S1614 | 15 BOLT (1/4-20X0.5-IN) | 2 | |
| 1B3922 | 16 CUP-BEARING | 2 | |
| 1H3338 | 17 LOCKWASHER | 2 | |
| 1K6975 | 18 SCREW-SET | 1 | |
| 2H3755 | 19 BOLT (5/16-18X0.43-IN) | 1 | |
| 3B4627 | 20 PIN-COTTER | 4 | |
| 3F9556 | 21 LOCKWASHER | 1 | |
| 4945819 | 22 LOCK | 1 | |
| 5021483 | 23 PLATE-CLUTCH | 1 | |
| 5021484 | 24 SLEEVE-CLUTCH | 1 | |
| 5021486 | 25 SHAFT-CLUTCH | 1 | |
| 5021487 | 26 NUT-HUB | 1 | |
| 5021488 | 27 LOCK-CLUTCH SCREW | 1 | |
| 5021489 | 28 RETAINER-BEARING | 1 | |
| 5021491 | 29 KEY (CLUTCH) | 1 | |
| 5021492 | 30 RING | 1 | |
| 5021493 | 31 HOUSING-CLUTCH | 1 | |
| 5664668 | 32 KEY-WOODRUFF | 2 | |
| 5664672 | 33 PIN | 8 | |
| 5664674 | 34 PIN | 4 | |
| 5664685 | 35 PIN-COTTER | 8 | |
| 5664697 | 36 RING-SNAP | 1 | |
| 5726482 | 37 PLATE-INSTRUCTION | 1 | |
| 5B2410 | 38 HOSE AS | 1 | |
| 6B3183 | 39 CONE-BEARING | 2 | |
| 6F0253 | 40 LOCKWASHER | 1 | |
| 9S1354 | 41 NUT (5/8-18-THD) | 1 |
