System And Components
296-9896 LINES GP-TURBOCHARGER AIRS/N P9L1-UP
Group No: 296-9896
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7W1944 | 1 RETAINER | 2 | |
| 1440367 | 2 CLAMP-HOSE | 8 | |
| 2056041 | 3 HOSE | 2 | |
| 2485564 | 4 SHUTOFF GP-AIR (TURBOCHARGER AIR LINE) | 1 | |
| 2974306 | 5 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 2974307 | 6 TUBE AS | 1 | |
| 3070139 | 7 TUBE | 1 | |
| 0S1594 | 8 BOLT (3/8-16X1-IN) | 2 | |
| 5M2894 | 9 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 3P0654 | 10 SEAL-O-RING | 1 | |
| 5L3244 | 11 CLIP | 2 | |
| 5P5700 | 12 SEAL-O-RING | 2 | |
| 6V5219 | 13 BOLT (M8X1.25X40-MM) | 4 | |
| 6V6889 | 14 NUT (M8X1.25-THD) | 2 | |
| 8T4121 | 15 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4136 | 16 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4224 | 17 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9M1974 | 18 WASHER-HARD (8.8X16X2-MM THK) | 4 |
