System And Components
257-2705 LINES GP-AIR COMPRESSORS/N PDZ1-UP
Group No: 257-2705
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2396896 | 1 TUBE AS | 1 | |
| 2409982 | 2 BRACKET | 1 | |
| 2572707 | 3 HOSE AS | 1 | |
| 2578751 | 4 VALVE AS (AIR COMPRESSOR) | 1 | |
| 6V7728 | 4A BOLT (M6X1X45-MM) | 4 | |
| 1785544 | 4B SPACER (6.6X13X18-MM THK) | 4 | |
| 2454393 | 4C GASKET | 1 | |
| 3535133 | 5 ELBOW AS | 1 | |
| 0307949 | ELBOW | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3849225 | 6 CONNECTOR AS | 1 | |
| 0308190 | CONNECTOR | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 9X8268 | 7 WASHER (17.5X30X3.5-MM THK) | 2 | |
| 3849227 | 8 CONNECTOR AS | 1 | |
| 2R6276 | CONNECTOR | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3849224 | 9 ELBOW AS | 1 | |
| 8K2377 | ELBOW-FLARED | 1 | |
| 2385083 | SEAL-O-RING | 1 | |
| 6V3940 | 10 BOLT (M8X1.25X25-MM) | 2 | |
| 9M1974 | 11 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 6V5224 | 12 BOLT (M16X2X25-MM) | 2 |
